System And Components
464-8673 HOOD & GUARD GPS/N KCS1-20000; LJY1-20000
Group No: 464-8673 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I0118 | 1 HOOK AS | 2 | |
| 7Y2853 | 2 SPACER (13X38X5-MM THK) | 6 | |
| 1703016 | 3 SPACER (19X32X2-MM THK) | 14 | |
| 2447789 | 4 SPACER (19X38X3-MM THK) | 8 | |
| 2658463 | 5 STUD-BALL (M8X1.25X16-MM) | 2 | |
| 2983112 | 6 HANDRAIL | 1 | |
| 3205784 | 7 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3205811 | 8 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3205827 | 9 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3205863 | 10 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3272859 | 11 SUPPORT AS | 1 | |
| 3272872 | LINER | 1 | |
| 3272884 | 12 BRACKET AS | 2 | |
| 3272886 | 13 STRIKER AS | 2 | |
| 3272889 | 14 SHEET AS | 1 | |
| 3485409 | SEAL (13-DM) | ||
| 3272914 | 15 SUPPORT AS-ENCLOSURE | 1 | |
| 3272932 | 16 SUPPORT AS | 1 | |
| 3272971 | 17 COVER AS-SOUND SUPPRESSION | 1 | |
| 3301304 | 18 DOOR GP-ACCESS (AIR CLEANER, BATTERY) | 1 | |
| 3301305 | 19 DOOR GP-ACCESS (RADIATOR) | 1 | |
| 3301306 | 20 DOOR GP-ACCESS (PUMP COMPARTMENT) | 1 | |
| 3301627 | 21 COVER AS | 1 | |
| 4I7924 | WASHER (4.5X40X1.2-MM THK) | 2 | |
| 6P2216 | CAP (PUSH ON) | 2 | |
| 3301631 | SILENCER | 1 | |
| 3301632 | 22 SHEET | 1 | |
| 4777692 | 23 SUPPORT AS | 1 | |
| 3397236 | 24 SUPPORT AS | 2 | |
| 3397383 | 25 SUPPORT AS | 1 | |
| 3397384 | 26 SUPPORT AS | 1 | |
| 3397648 | 27 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3397649 | LINER | 1 | |
| 3397651 | 28 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3432295 | 29 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3432465 | 30 BUMPER | 4 | |
| 3432466 | 31 SHEET AS | 1 | |
| 3485409 | SEAL (4-DM) | ||
| 3597996 | 32 SUPPORT AS | 1 | |
| 3667220 | 33 SUPPORT AS-SOUND SUPPRESSION | 1 | |
| 3828630 | 34 ROLLER | 1 | |
| 3852314 | 35 SPRING | 1 | |
| 3903656 | 36 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3903661 | 37 SUPPORT AS | 1 | |
| 3922059 | 38 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3922065 | 39 SUPPORT AS | 1 | |
| 4640593 | LINER | 1 | |
| 3922081 | 40 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3922086 | 41 SUPPORT AS | 1 | |
| 3922091 | 42 LINER | 1 | |
| 3922099 | 43 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3922103 | 44 SHEET AS-SOUND SUPPRESSION | 1 | |
| 4250023 | 45 HOOD GP-ENGINE (HINGED) | 1 | |
| 4250024 | 46 HOOD GP-ENGINE (HINGED) | 1 | |
| 4309414 | 47 FASTENER | 1 | |
| 4347790 | 48 SPRING AS-GAS (LOCKABLE) | 1 | |
| 4382381 | 49 SHEET AS | 1 | |
| 4382437 | LINER | 1 | |
| 4452222 | 50 COVER AS-SOUND SUPPRESSION (FUEL, HYDRAULIC TANKS) | 1 | |
| 4458140 | 51 SUPPORT AS | 1 | |
| 4458186 | 52 SHEET AS | 1 | |
| 4I7924 | WASHER (4.5X40X1.2-MM THK) | 3 | |
| 6P2216 | CAP (PUSH ON) | 3 | |
| 4472506 | SILENCER | 1 | |
| 4467065 | 53 SHEET AS-SOUND SUPPRESSION | 1 | |
| 4467066 | 54 SHEET AS | 1 | |
| 3432514 | LINER | 1 | |
| 3485409 | SEAL (15-DM) | ||
| 4467067 | 55 SUPPORT AS-SOUND SUPPRESSION | 1 | |
| 4467069 | 56 SUPPORT AS | 1 | |
| 4467077 | 57 SUPPORT AS | 1 | |
| 3536757 | SEAL (14-DM) | ||
| 4503418 | 58 SUPPORT AS | 1 | |
| 3272913 | LINER | 1 | |
| 3485409 | SEAL (14-DM) | ||
| 4542383 | 59 SUPPORT AS | 1 | |
| 4595077 | 60 COVER AS-SOUND SUPPRESSION | 1 | |
| 3272966 | INSULATION | 3 | |
| 4642262 | 61 SUPPORT AS-SOUND SUPPRESSION | 1 | |
| 4649530 | 62 SUPPORT AS | 1 | |
| 4667704 | 63 SHEET | 1 | |
| 1358573 | 64 BOLT AS | 43 | |
| 1358575 | 65 BOLT AS | 101 | |
| 1358577 | 66 BOLT AS | 6 | |
| 5C7261 | 67 NUT (M8X1.25-THD) | 2 | |
| 5P0372 | 68 LOCK PIN | 1 | |
| 5P1076 | 69 WASHER-HARD (13.5X30X4-MM THK) | 1 | |
| 7Y2854 | 70 SPACER (24X38X3-MM THK) | 6 | |
| 7Y2916 | 71 PIN-CLEVIS | 1 | |
| 8T4121 | 72 WASHER-HARD (11X21X2.5-MM THK) | 24 | |
| 8T4133 | 73 NUT (M10X1.5-THD) | 4 | |
| 8T4136 | 74 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4137 | 75 BOLT (M10X1.5X20-MM) | 11 | |
| 8T4189 | 76 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4191 | 77 BOLT (M10X1.5X16-MM) | 7 | |
| 8T4196 | 78 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4223 | 79 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4224 | 80 WASHER-HARD (8.8X16X2-MM THK) | 6 |
