426-2671 SHEAR AR-HYDRAULICS/N LX31-UP; SXD1-UP

Group No: 426-2671
Part NumberPart NameQty
6V77421 NUT-FULL (M20X2.5-THD)1
41717322 ROTATOR GP-HYDRAULIC1
43547173 PLATE & FILM GP1
43553934 PLATE-LOCK1
44308585 HOUSING GP-SHEAR (HYDRAULIC)1
44310096 PLATE-LOCK1
44513617 MANIFOLD2
44692788 COVER2
10225629 BOLT-SOCKET HEAD (M16X2X180-MM)8
159112110 LOCKWASHER8
1P370411 SEAL-RECTANGULAR4
1P370512 SEAL-RECTANGULAR2
1P576713 FLANGE-HALF8
2S407814 SEAL-O-RING2
5P004815 COVER4
6V353116 BOLT (M20X2.5X50-MM)2
7X257717 BOLT (M24X3X90-MM)22
7Y524118 BOLT-SOCKET HEAD (M20X2.5X60-MM)1
8T416719 WASHER-HARD (26X44X4-MM THK)22
8T419220 BOLT (M12X1.75X25-MM)8
8T419421 BOLT (M12X1.75X50-MM)16
8T422322 WASHER-HARD (13.5X25.5X3-MM THK)24
8T643023 BOLT (M20X2.5X50-MM)2
360369824 PLUG2
6V085225 CAP-DUST2
3J190726 SEAL-O-RING2
6V396527 FITTING (QUICK DISCONNECT)2
463105628 BUMPER2
8T038929 LOCKNUT (M10X1.5-THD)4
8T412130 WASHER-HARD (11X21X2.5-MM THK)8
8T418531 BOLT (M10X1.5X50-MM)4
