System And Components
435-9356 SHEAR AR-HYDRAULICS/N LX51-UP; SXG1-UP
Group No: 435-9356
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1591121 | 1 LOCKWASHER | 8 | |
| 4853840 | 2 ROTATOR GP-HYDRAULIC | 1 | |
| 4355393 | 3 PLATE-LOCK | 1 | |
| 4359359 | 4 PLATE & FILM GP | 1 | |
| 4433051 | 5 HOUSING GP-SHEAR (HYDRAULIC) | 1 | |
| 4433068 | 6 PLATE-LOCK | 1 | |
| 4451361 | 7 MANIFOLD | 2 | |
| 1022562 | 8 BOLT-SOCKET HEAD (M16X2X180-MM) | 8 | |
| 1P3704 | 9 SEAL-RECTANGULAR | 4 | |
| 1P3705 | 10 SEAL-RECTANGULAR | 2 | |
| 1P5767 | 11 FLANGE-HALF | 8 | |
| 2S4078 | 12 SEAL-O-RING | 2 | |
| 5P0048 | 13 COVER | 4 | |
| 6V7742 | 14 NUT-FULL (M20X2.5-THD) | 1 | |
| 7Y5217 | 15 BOLT-SOCKET HEAD (M20X2.5X70-MM) | 1 | |
| 8T4123 | 16 WASHER (22X35X3.5-MM THK) | 34 | |
| 2135007 | 17 BOLT (M20X2.5X80-MM) | 34 | |
| 8T4194 | 18 BOLT (M12X1.75X50-MM) | 16 | |
| 8T4223 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 8T6430 | 20 BOLT (M20X2.5X50-MM) | 4 | |
| 3603698 | 21 PLUG | 2 |
