System And Components
451-9968 SHEAR AR-HYDRAULICS/N LX31-UP; SXD1-UP
Group No: 451-9968
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3603698 | 1 PLUG | 2 | |
| 4171738 | 2 ROTATOR GP-HYDRAULIC | 1 | |
| 4354717 | 3 PLATE & FILM GP | 1 | |
| 4355393 | 4 PLATE-LOCK | 1 | |
| 4430858 | 5 HOUSING GP-SHEAR (HYDRAULIC) | 1 | |
| 4431009 | 6 PLATE-LOCK | 1 | |
| 4451361 | 7 MANIFOLD | 2 | |
| 1022562 | 8 BOLT-SOCKET HEAD (M16X2X180-MM) | 8 | |
| 1591121 | 9 LOCKWASHER | 8 | |
| 1P3704 | 10 SEAL-RECTANGULAR | 4 | |
| 1P3705 | 11 SEAL-RECTANGULAR | 2 | |
| 1P5767 | 12 FLANGE-HALF | 8 | |
| 2S4078 | 13 SEAL-O-RING | 2 | |
| 5P0048 | 14 COVER | 4 | |
| 6V3531 | 15 BOLT (M20X2.5X50-MM) | 2 | |
| 6V7742 | 16 NUT-FULL (M20X2.5-THD) | 1 | |
| 7X2577 | 17 BOLT (M24X3X90-MM) | 24 | |
| 7Y5241 | 18 BOLT-SOCKET HEAD (M20X2.5X60-MM) | 1 | |
| 8T4167 | 19 WASHER-HARD (26X44X4-MM THK) | 24 | |
| 8T4194 | 20 BOLT (M12X1.75X50-MM) | 16 | |
| 8T4223 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 8T6430 | 22 BOLT (M20X2.5X50-MM) | 2 |
