System And Components
528-6369 SHEAR AR-HYDRAULICS/N LX51-UP; SXG1-UP
Group No: 528-6369
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1022562 | 1 BOLT-SOCKET HEAD (M16X2X180-MM) | 8 | |
| 8T6430 | 2 BOLT (M20X2.5X50-MM) | 4 | |
| 3603679 | 3 PLUG-CONNECTOR (9/16-18-THD) | 2 | |
| 4355393 | 4 PLATE-LOCK | 1 | |
| 4359359 | 5 PLATE & FILM GP | 1 | |
| 4433051 | 6 HOUSING GP-SHEAR (HYDRAULIC) | 1 | |
| 4433068 | 7 PLATE-LOCK | 1 | |
| 5109291 | 8 MANIFOLD AS | 2 | |
| 5286370 | 9 ROTATOR GP-HYDRAULIC | 1 | |
| 1360155 | 10 SETSCREW (M4X0.7X8-MM) | 2 | |
| 1591121 | 11 LOCKWASHER | 8 | |
| 1P3704 | 12 SEAL-RECTANGULAR | 4 | |
| 1P3705 | 13 SEAL-RECTANGULAR | 2 | |
| 1P5767 | 14 FLANGE-HALF | 8 | |
| 3J1907 | 15 SEAL-O-RING | 2 | |
| 5P0048 | 16 COVER | 4 | |
| 7Y5217 | 17 BOLT-SOCKET HEAD (M20X2.5X70-MM) | 1 | |
| 8T4123 | 18 WASHER (22X35X3.5-MM THK) | 32 | |
| 8T4131 | 19 NUT (M20X2.5-THD) | 1 | |
| 2135007 | 20 BOLT (M20X2.5X80-MM) | 32 | |
| 8T4194 | 21 BOLT (M12X1.75X50-MM) | 16 | |
| 8T4223 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 16 |
