System And Components
448-2630 SHEAR GP-HYDRAULIC -REACH BOOMS/N SX81-UP; B7W1-UP
Group No: 448-2630
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1591121 | 1 LOCKWASHER | 8 | |
| 4355393 | 2 PLATE-LOCK | 1 | |
| 4433068 | 3 PLATE-LOCK | 1 | |
| 4482631 | 4 HOUSING GP-SHEAR (HYDRAULIC) | 1 | |
| 4490925 | 5 FILM GP (S3090) | 1 | |
| 4867651 | 6 ROTATOR GP-HYDRAULIC | 1 | |
| 4912818 | 7 MANIFOLD AS | 2 | |
| 1022562 | 8 BOLT-SOCKET HEAD (M16X2X180-MM) | 8 | |
| 1P3705 | 9 SEAL-RECTANGULAR | 6 | |
| 3J1907 | 10 SEAL-O-RING | 2 | |
| 5P0049 | 11 COVER | 4 | |
| 5P8077 | 12 FLANGE-HALF | 8 | |
| 6V0852 | 13 CAP-DUST | 2 | |
| 6V3965 | 14 FITTING (QUICK DISCONNECT) | 2 | |
| 8T4131 | 15 NUT (M20X2.5-THD) | 1 | |
| 7X2489 | 16 BOLT (M24X3X100-MM) | 46 | |
| 7Y5217 | 17 BOLT-SOCKET HEAD (M20X2.5X70-MM) | 1 | |
| 8T4122 | 18 WASHER-HARD (17X32X3.5-MM THK) | 16 | |
| 8T4140 | 19 BOLT (M16X2X60-MM) | 16 | |
| 8T4167 | 20 WASHER-HARD (26X44X4-MM THK) | 46 | |
| 8T6430 | 21 BOLT (M20X2.5X50-MM) | 4 |
