System And Components
494-0637 SHEAR GP-HYDRAULICS/N LX51-UP; SXG1-UP
Group No: 494-0637
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1022562 | 1 BOLT-SOCKET HEAD (M16X2X180-MM) | 8 | |
| 1591121 | 2 LOCKWASHER | 8 | |
| 3J1907 | 3 SEAL-O-RING | 2 | |
| 4355393 | 4 PLATE-LOCK | 1 | |
| 4359359 | 5 PLATE & FILM GP | 1 | |
| 4433051 | 6 HOUSING GP-SHEAR (HYDRAULIC) | 1 | |
| 4433068 | 7 PLATE-LOCK | 1 | |
| 5109291 | 8 MANIFOLD AS | 2 | |
| 4940639 | 9 ROTATOR GP-HYDRAULIC | 1 | |
| 1P3704 | 10 SEAL-RECTANGULAR | 4 | |
| 1P3705 | 11 SEAL-RECTANGULAR | 2 | |
| 1P5767 | 12 FLANGE-HALF | 8 | |
| 6V3965 | 13 FITTING (QUICK DISCONNECT) | 2 | |
| 5P0048 | 14 COVER | 4 | |
| 8T4131 | 15 NUT (M20X2.5-THD) | 1 | |
| 7Y5217 | 16 BOLT-SOCKET HEAD (M20X2.5X70-MM) | 1 | |
| 8T4123 | 17 WASHER (22X35X3.5-MM THK) | 34 | |
| 2135007 | 18 BOLT (M20X2.5X80-MM) | 34 | |
| 8T4194 | 19 BOLT (M12X1.75X50-MM) | 16 | |
| 8T4223 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 8T6430 | 21 BOLT (M20X2.5X50-MM) | 4 | |
| 6V0852 | 22 CAP-DUST | 2 | |
| 1360155 | 23 SETSCREW (M4X0.7X8-MM) | 2 |
