System And Components
501-0645 SHEAR GP-HYDRAULICS/N LX51-UP; SXG1-UP
Group No: 501-0645
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3240938 | 1 PLATE | 2 | |
| 1360155 | 2 SETSCREW (M4X0.7X8-MM) | 2 | |
| 4355393 | 3 PLATE-LOCK | 1 | |
| 4359359 | 4 PLATE & FILM GP | 1 | |
| 4433051 | 5 HOUSING GP-SHEAR (HYDRAULIC) | 1 | |
| 4433068 | 6 PLATE-LOCK | 1 | |
| 5000391 | 7 ROTATOR GP-HYDRAULIC | 1 | |
| 5100811 | 8 PLATE | 1 | |
| 5118995 | 9 MANIFOLD | 2 | |
| 7X2607 | 10 BOLT (M12X1.75X130-MM) | 2 | |
| 1591119 | 11 LOCKWASHER | 2 | |
| 1591121 | 12 LOCKWASHER | 8 | |
| 1P3704 | 13 SEAL-RECTANGULAR | 2 | |
| 1P3705 | 14 SEAL-RECTANGULAR | 2 | |
| 1P5767 | 15 FLANGE-HALF | 4 | |
| 5P0048 | 17 COVER | 2 | |
| 8T4131 | 18 NUT (M20X2.5-THD) | 1 | |
| 7Y5217 | 19 BOLT-SOCKET HEAD (M20X2.5X70-MM) | 1 | |
| 7Y5244 | 20 BOLT-SOCKET HEAD | 8 | |
| 8T4123 | 21 WASHER (22X35X3.5-MM THK) | 32 | |
| 2135007 | 22 BOLT (M20X2.5X80-MM) | 32 | |
| 8T4193 | 23 BOLT (M16X2X50-MM) | 4 | |
| 8T4194 | 24 BOLT (M12X1.75X50-MM) | 8 | |
| 8T4223 | 25 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T6430 | 26 BOLT (M20X2.5X50-MM) | 4 | |
| 9X8257 | 27 WASHER (17.5X30X3.5-MM THK) | 4 |
