System And Components
506-1005 SHEAR GP-HYDRAULIC -BOOM MOUNTEDS/N SX81-UP; B7W1-UP
Group No: 506-1005
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1591121 | 1 LOCKWASHER | 8 | |
| 8T6430 | 2 BOLT (M20X2.5X50-MM) | 4 | |
| 4355393 | 3 PLATE-LOCK | 1 | |
| 4433068 | 4 PLATE-LOCK | 1 | |
| 4482631 | 5 HOUSING GP-SHEAR (HYDRAULIC) | 1 | |
| 4490925 | 6 FILM GP (S3090) | 1 | |
| 4912818 | 7 MANIFOLD AS | 2 | |
| 5061004 | 8 ROTATOR GP-HYDRAULIC | 1 | |
| 1022562 | 9 BOLT-SOCKET HEAD (M16X2X180-MM) | 8 | |
| 1360155 | 10 SETSCREW (M4X0.7X8-MM) | 2 | |
| 1P3705 | 11 SEAL-RECTANGULAR | 6 | |
| 3J1907 | 12 SEAL-O-RING | 2 | |
| 5P0049 | 13 COVER | 4 | |
| 5P8077 | 14 FLANGE-HALF | 8 | |
| 6V0852 | 15 CAP-DUST | 2 | |
| 6V3965 | 16 FITTING (QUICK DISCONNECT) | 2 | |
| 7X2489 | 17 BOLT (M24X3X100-MM) | 46 | |
| 7Y5217 | 18 BOLT-SOCKET HEAD (M20X2.5X70-MM) | 1 | |
| 8T4122 | 19 WASHER-HARD (17X32X3.5-MM THK) | 16 | |
| 8T4131 | 20 NUT (M20X2.5-THD) | 1 | |
| 8T4140 | 21 BOLT (M16X2X60-MM) | 16 | |
| 8T4167 | 22 WASHER-HARD (26X44X4-MM THK) | 46 |
