System And Components
382-4394 HOUSING GP-SHEAR -HYDRAULICS/N LX21-UP
Group No: 382-4394
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5W2817 | 1 FITTING-GREASE | 5 | |
| 6V0852 | 2 CAP-DUST | 2 | |
| 1950785 | 3 BEARING | 2 | |
| 1950792 | 4 LOCK PIN | 2 | |
| 3816731 | 5 CYLINDER & VALVE GP | 1 | |
| 3816743 | 6 KEEPER | 4 | |
| 3816744 | 7 PIN | 1 | |
| 3824462 | 8 HOUSING AS | 1 | |
| 4404719 | 8A PLATE-WEAR | 1 | |
| 1925238 | 8B PLATE-HOLDER (SERIAL NUMBER) | 1 | |
| 3826958 | 9 PIN-ROD | 1 | |
| 3833049 | 10 PIN | 1 | |
| 3834156 | 11 EDGE GP-CUTTING | 1 | |
| 3834217 | 12 SHIM (1-MM THK) | 2 | |
| 3834219 | 13 PLATE-LOCK | 1 | |
| 3834221 | 14 COVER | 1 | |
| 3841568 | 15 BUSHING | 1 | |
| 4355303 | 16 SHIM (2-MM THK) | 2 | |
| 4526862 | 17 JAW AS-UPPER | 1 | |
| 3816741 | 17A BEARING-SLEEVE | 2 | |
| 3834149 | 17B BEARING-SLEEVE | 2 | |
| 4993538 | 18 MANIFOLD AS | 2 | |
| 4799266 | 19 NUT | 1 | |
| 0950707 | 20 BOLT (M16X2X120-MM) | 8 | |
| 1591121 | 21 LOCKWASHER | 14 | |
| 1592953 | 22 SCREW-FLAT HEAD (M16X2-THD) | 8 | |
| 1P3704 | 23 SEAL-RECTANGULAR | 4 | |
| 1P3705 | 24 SEAL-RECTANGULAR | 2 | |
| 1P5767 | 25 FLANGE-HALF | 8 | |
| 8T6430 | 26 BOLT (M20X2.5X50-MM) | 2 | |
| 3J1907 | 27 SEAL-O-RING | 2 | |
| 5P0048 | 28 COVER | 4 | |
| 6V3965 | 29 FITTING (QUICK DISCONNECT) | 2 | |
| 8C8840 | 30 RING-RETAINING | 8 | |
| 8T0439 | 31 BOLT-SOCKET HEAD (M16X2X30-MM) | 6 | |
| 8T4123 | 32 WASHER (22X35X3.5-MM THK) | 2 | |
| 8T4194 | 33 BOLT (M12X1.75X50-MM) | 16 | |
| 8T4223 | 34 WASHER-HARD (13.5X25.5X3-MM THK) | 16 |
