System And Components
422-8971 HOUSING GP-SHEAR -HYDRAULICS/N LX41-UP; SXF1-UP
Group No: 422-8971
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5W2817 | 1 FITTING-GREASE | 5 | |
| 1591121 | 2 LOCKWASHER | 14 | |
| 2273761 | 3 BEARING | 2 | |
| 3932775 | 4 HOUSING AS | 1 | |
| 4414304 | 4A PLATE-WEAR | 1 | |
| 1925238 | 4B PLATE-HOLDER (SERIAL NUMBER) | 1 | |
| 4229904 | 5 PIN-CYLINDER | 1 | |
| 4229905 | 6 PLATE-ROTATOR | 4 | |
| 4229906 | 7 CYLINDER & VALVE GP | 1 | |
| 4232034 | 8 SHIM (1-MM THK) | 2 | |
| 4232036 | 10 JAW GP-SHEAR | 1 | |
| 4232039 | 11 BUSHING | 1 | |
| 4232041 | 12 PIN-LOCK | 2 | |
| 4232043 | 13 NUT | 1 | |
| 4232044 | 14 PLATE-LOCK | 1 | |
| 4232045 | 15 PLATE | 1 | |
| 4232048 | 16 PIN-CYLINDER | 1 | |
| 4232052 | 17 EDGE GP-CUTTING | 1 | |
| 4232626 | 18 PIN | 1 | |
| 4357951 | 20 SHIM (2-MM THK) | 2 | |
| 4724917 | 21 MANIFOLD | 2 | |
| 0950707 | 22 BOLT (M16X2X120-MM) | 8 | |
| 1592953 | 23 SCREW-FLAT HEAD (M16X2-THD) | 8 | |
| 1P3704 | 24 SEAL-RECTANGULAR | 4 | |
| 1P3705 | 25 SEAL-RECTANGULAR | 2 | |
| 1P5767 | 26 FLANGE-HALF | 8 | |
| 2S4078 | 27 SEAL-O-RING | 2 | |
| 5P0048 | 28 COVER | 4 | |
| 8C8840 | 29 RING-RETAINING | 8 | |
| 8T0439 | 30 BOLT-SOCKET HEAD (M16X2X30-MM) | 6 | |
| 8T4123 | 31 WASHER (22X35X3.5-MM THK) | 2 | |
| 8T4194 | 32 BOLT (M12X1.75X50-MM) | 16 | |
| 8T4223 | 33 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 8T6430 | 34 BOLT (M20X2.5X50-MM) | 2 | |
| 3603698 | 35 PLUG | 2 |
