System And Components
436-3850 HOUSING GP-SHEAR -HYDRAULICS/N SX71-UP; BPB1-UP
Group No: 436-3850
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4371231 | 1 HOUSING AS | 1 | |
| 4418409 | 1A PLATE-WEAR | 1 | |
| 1925238 | 1B PLATE-HOLDER (SERIAL NUMBER) | 1 | |
| 5W2817 | 2 FITTING-GREASE | 5 | |
| 2405946 | 3 BEARING | 2 | |
| 4232041 | 4 PIN-LOCK | 2 | |
| 4242031 | 5 PIN-CYLINDER | 1 | |
| 4242032 | 6 PIN-CYLINDER | 1 | |
| 4242033 | 7 PLATE-ROTATOR | 4 | |
| 4242035 | 8 CYLINDER & VALVE GP | 1 | |
| 4432748 | 9 EDGE GP-CUTTING | 1 | |
| 4443638 | 10 JAW GP-SHEAR | 1 | |
| 4449761 | 11 SHIM (1-MM THK) | 2 | |
| 4449763 | 12 BUSHING | 1 | |
| 4449764 | 13 PIN | 1 | |
| 4449765 | 14 NUT | 1 | |
| 4449766 | 15 PLATE-LOCK | 1 | |
| 4449768 | 16 COVER | 1 | |
| 4449770 | 17 SHIM (2-MM THK) | 2 | |
| 4904750 | 18 MANIFOLD AS | 2 | |
| 0960008 | 19 BOLT-SOCKET HEAD (M16X2X140-MM) | 8 | |
| 1591121 | 20 LOCKWASHER | 14 | |
| 1592953 | 21 SCREW-FLAT HEAD (M16X2-THD) | 8 | |
| 1P3705 | 22 SEAL-RECTANGULAR | 6 | |
| 3J1907 | 23 SEAL-O-RING | 2 | |
| 5P0049 | 24 COVER | 4 | |
| 5P8077 | 25 FLANGE-HALF | 8 | |
| 6V0852 | 26 CAP-DUST | 2 | |
| 6V3965 | 27 FITTING (QUICK DISCONNECT) | 2 | |
| 8C8840 | 28 RING-RETAINING | 8 | |
| 8T0439 | 29 BOLT-SOCKET HEAD (M16X2X30-MM) | 6 | |
| 8T4122 | 30 WASHER-HARD (17X32X3.5-MM THK) | 16 | |
| 8T4123 | 31 WASHER (22X35X3.5-MM THK) | 2 | |
| 8T4140 | 32 BOLT (M16X2X60-MM) | 16 | |
| 8T6430 | 33 BOLT (M20X2.5X50-MM) | 2 |
