System And Components
Assembly
100%

443-0858 HOUSING GP-SHEAR -HYDRAULICS/N LX31-UP; SXD1-UP

Group No: 443-0858
Part NumberPart NameQty
5W28171 FITTING-GREASE5
6V83993 SEAL-O-RING2
19507854 BEARING2
19507925 LOCK PIN2
35150496 HOSE AS1
38167437 KEEPER4
38167448 PIN1
38269589 PIN-ROD1
383304910 PIN1
383415611 EDGE GP-CUTTING1
383421712 SHIM (1-MM THK)2
383421913 PLATE-LOCK1
383422114 COVER1
384156815 BUSHING1
461944416 HOSE AS1
415189217 GEAR & BEARING AS1
2301621SEAL (532-CM)
5W2817FITTING-GREASE1
425449218 SWIVEL GP1
472298519 MANIFOLD2
479926620 NUT1
159111921 LOCKWASHER8
435530322 SHIM (2-MM THK)2
443079323 HOUSING AS1
4404719PLATE-WEAR1
1925238PLATE-HOLDER (SERIAL NUMBER)1
443100424 MANIFOLD AS1
452686225 JAW AS-UPPER1
381674125A BEARING-SLEEVE2
383414925B BEARING-SLEEVE2
159112126 LOCKWASHER6
3E691027 BOLT-SOCKET HEAD (M12X1.75X70-MM)8
159295328 SCREW-FLAT HEAD (M16X2-THD)8
1P370429 SEAL-RECTANGULAR6
1P370530 SEAL-RECTANGULAR2
1P576731 FLANGE-HALF8
381673132 CYLINDER & VALVE GP1
7X245433 BOLT (M24X3X110-MM)24
8C884034 RING-RETAINING8
8T043935 BOLT-SOCKET HEAD (M16X2X30-MM)6
8T412336 WASHER (22X35X3.5-MM THK)2
8T416737 WASHER-HARD (26X44X4-MM THK)24
8T414038 BOLT (M16X2X60-MM)4
8T419439 BOLT (M12X1.75X50-MM)16
8T422340 WASHER-HARD (13.5X25.5X3-MM THK)16
8T638241 BOLT (M16X2X260-MM)4
8T643042 BOLT (M20X2.5X50-MM)2
9X825743 WASHER (17.5X30X3.5-MM THK)4
198478044 WASHER-HARD (17.5X32X8-MM THK)4
3J190745 SEAL-O-RING2
9S419146 PLUG (9/16-18-THD)2
