System And Components
443-3051 HOUSING GP-SHEAR -HYDRAULICS/N LX31-UP; LX51-UP; SXD1-UP; SXG1-UP
Group No: 443-3051
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4254492 | 1 SWIVEL GP | 1 | |
| 5W2817 | 2 FITTING-GREASE | 5 | |
| 1591121 | 3 LOCKWASHER | 14 | |
| 2273761 | 4 BEARING | 2 | |
| 4229904 | 5 PIN-CYLINDER | 1 | |
| 4229905 | 6 PLATE-ROTATOR | 4 | |
| 4229906 | 7 CYLINDER & VALVE GP | 1 | |
| 4232034 | 8 SHIM (1-MM THK) | 2 | |
| 4232036 | 9 JAW GP-SHEAR | 1 | |
| 4232039 | 10 BUSHING | 1 | |
| 4232041 | 11 PIN-LOCK | 2 | |
| 4232043 | 12 NUT | 1 | |
| 4232044 | 13 PLATE-LOCK | 1 | |
| 4232045 | 14 PLATE | 1 | |
| 4232048 | 15 PIN-CYLINDER | 1 | |
| 4232052 | 16 EDGE GP-CUTTING | 1 | |
| 4232626 | 17 PIN | 1 | |
| 4235013 | 18 GEAR & BEARING AS | 1 | |
| 5W2817 | FITTING-GREASE | 4 | |
| 2301621 | SEAL (597-CM) | ||
| 4357951 | 19 SHIM (2-MM THK) | 2 | |
| 4372969 | 20 HOSE AS | 1 | |
| 4433052 | 21 HOUSING AS | 1 | |
| 4414304 | 21A PLATE-WEAR | 1 | |
| 1925238 | 21B PLATE-HOLDER (SERIAL NUMBER) | 1 | |
| 4433055 | 22 MANIFOLD AS | 1 | |
| 4655665 | 23 MANIFOLD | 2 | |
| 5122417 | 24 HOSE AS | 1 | |
| 1592953 | 25 SCREW-FLAT HEAD (M16X2-THD) | 8 | |
| 1984780 | 26 WASHER-HARD (17.5X32X8-MM THK) | 4 | |
| 1P3705 | 27 SEAL-RECTANGULAR | 8 | |
| 3E8008 | 28 BOLT-SOCKET HEAD (M16X2X90-MM) | 8 | |
| 5P8077 | 29 FLANGE-HALF | 8 | |
| 7X2532 | 30 BOLT (M20X2.5X130-MM) | 36 | |
| 8C8840 | 31 RING-RETAINING | 8 | |
| 8T0439 | 32 BOLT-SOCKET HEAD (M16X2X30-MM) | 6 | |
| 8T4122 | 33 WASHER-HARD (17X32X3.5-MM THK) | 16 | |
| 8T4123 | 34 WASHER (22X35X3.5-MM THK) | 38 | |
| 8T4140 | 35 BOLT (M16X2X60-MM) | 20 | |
| 8T6382 | 36 BOLT (M16X2X260-MM) | 4 | |
| 8T6430 | 37 BOLT (M20X2.5X50-MM) | 2 | |
| 9X8257 | 38 WASHER (17.5X30X3.5-MM THK) | 4 | |
| 3J1907 | 39 SEAL-O-RING | 2 | |
| 9S4191 | 40 PLUG (9/16-18-THD) | 2 | |
| 6V8399 | 41 SEAL-O-RING | 2 | |
| 4232035 | SHIM (1.6-MM THK) | 1 |
