System And Components
448-2631 HOUSING GP-SHEAR -HYDRAULICS/N SX81-UP; B7W1-UP
Group No: 448-2631
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4254492 | 1 SWIVEL GP | 1 | |
| 1591121 | 2 LOCKWASHER | 14 | |
| 4482633 | 3 HOUSING AS | 1 | |
| 4418409 | PLATE-WEAR | 1 | |
| 5W2817 | 4 FITTING-GREASE | 5 | |
| 2405946 | 5 BEARING | 2 | |
| 4232041 | 6 PIN-LOCK | 2 | |
| 4242031 | 7 PIN-CYLINDER | 1 | |
| 4242032 | 8 PIN-CYLINDER | 1 | |
| 4242033 | 9 PLATE-ROTATOR | 4 | |
| 4242035 | 10 CYLINDER & VALVE GP | 1 | |
| 4372969 | 11 HOSE AS | 1 | |
| 4432748 | 12 EDGE GP-CUTTING | 1 | |
| 4433055 | 13 MANIFOLD AS | 1 | |
| 4443638 | 14 JAW GP-SHEAR | 1 | |
| 4449761 | 15 SHIM (1-MM THK) | 2 | |
| 4449763 | 16 BUSHING | 1 | |
| 4449764 | 17 PIN | 1 | |
| 4449765 | 18 NUT | 1 | |
| 4449766 | 19 PLATE-LOCK | 1 | |
| 4449768 | 20 COVER | 1 | |
| 4449770 | 21 SHIM (2-MM THK) | 2 | |
| 4472438 | 22 GEAR & BEARING AS | 1 | |
| 5W2817 | FITTING-GREASE | 4 | |
| 2301621 | SEAL (670-CM) | ||
| 4655665 | 23 MANIFOLD | 2 | |
| 5122417 | 24 HOSE AS | 1 | |
| 1592953 | 25 SCREW-FLAT HEAD (M16X2-THD) | 8 | |
| 1984780 | 26 WASHER-HARD (17.5X32X8-MM THK) | 4 | |
| 1P3705 | 27 SEAL-RECTANGULAR | 8 | |
| 3E8008 | 28 BOLT-SOCKET HEAD (M16X2X90-MM) | 8 | |
| 3J1907 | 29 SEAL-O-RING | 2 | |
| 5P8077 | 30 FLANGE-HALF | 8 | |
| 6V8399 | 31 SEAL-O-RING | 2 | |
| 8C8840 | 32 RING-RETAINING | 8 | |
| 8T0439 | 33 BOLT-SOCKET HEAD (M16X2X30-MM) | 6 | |
| 8T4122 | 34 WASHER-HARD (17X32X3.5-MM THK) | 16 | |
| 8T4123 | 35 WASHER (22X35X3.5-MM THK) | 2 | |
| 8T4140 | 36 BOLT (M16X2X60-MM) | 20 | |
| 8T4167 | 37 WASHER-HARD (26X44X4-MM THK) | 48 | |
| 8T6380 | 38 BOLT (M24X3X130-MM) | 48 | |
| 8T6382 | 39 BOLT (M16X2X260-MM) | 4 | |
| 8T6430 | 40 BOLT (M20X2.5X50-MM) | 2 | |
| 9S4191 | 41 PLUG (9/16-18-THD) | 2 | |
| 9X8257 | 42 WASHER (17.5X30X3.5-MM THK) | 4 |
