System And Components
472-4788 CYLINDER GP-SHEARS/N LX21-UP; LX31-UP; SXD1-UP
Group No: 472-4788
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3816741 | 1 BEARING-SLEEVE | 2 | |
| 3865911 | 2 SEAL-O-RING | 1 | |
| 3990336 | 3 CYLINDER AS-HYDRAULIC | 1 | |
| 4195018 | 4 PISTON | 1 | |
| 4195019 | 5 HEAD | 1 | |
| 4196288 | 6 BOLT-SOCKET HEAD | 10 | |
| 4724789 | 7 ROD AS | 1 | |
| 4843467 | PLUG-PIPE | 1 | |
| 4854632 | 9 SEAL-WIPER | 1 | |
| 4854633 | 10 SEAL-U-CUP | 1 | |
| 4854634 | 11 SEAL AS | 1 | |
| 4854635 | 12 RING-BACKUP | 1 | |
| 4854636 | 13 RING-BACKUP | 2 | |
| 4854637 | 14 SEAL AS-PISTON | 1 | |
| 4854638 | 15 RING-WEAR | 2 | |
| 4854639 | 16 RING-WEAR | 3 | |
| 4854640 | 17 SEAL-O-RING | 1 | |
| 3E6501 | 18 LOCKWASHER | 24 | |
| 9X8915 | 19 BOLT-SOCKET HEAD (M24X3X130-MM) | 24 | |
| 4857129 | KIT-CYLINDER SEAL | 1 |
