System And Components
478-1061 CYLINDER GP-SHEARS/N LX31-UP; LX41-UP; LX51-UP; SXD1-UP; SXF1-UP; SXG1-UP
Group No: 478-1061
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4229909 | 1 BEARING-SLEEVE | 2 | |
| 4229910 | 2 CYLINDER AS | 1 | |
| 4229921 | 3 PISTON | 1 | |
| 4229922 | 4 HEAD | 1 | |
| 4339844 | 5 BOLT-SOCKET HEAD (M30X3.5-THD) | 24 | |
| 4781062 | 6 ROD AS | 1 | |
| 4843467 | PLUG-PIPE | 1 | |
| 4860733 | 7 TUBE | 1 | |
| 4883802 | 8 SEAL-WIPER | 1 | |
| 4883805 | 9 SEAL-U-CUP | 1 | |
| 4883807 | 10 RING-BACKUP | 1 | |
| 4883808 | 11 RING-BACKUP | 2 | |
| 4883811 | 12 SEAL AS-BUFFER | 1 | |
| 4883812 | 13 SEAL AS-PISTON | 1 | |
| 5781193 | 14 RING-WEAR | 3 | |
| 5781194 | 15 RING-WEAR | 2 | |
| 4883857 | 17 SEAL-O-RING | 1 | |
| 4883856 | 18 SEAL-O-RING | 1 | |
| 4895231 | 19 LOCKWASHER | 24 | |
| 2259439 | 20 BOLT-SOCKET HEAD | 10 | |
| 4887710 | KIT-CYLINDER SEAL | 1 |
