System And Components
486-7651 ROTATOR GP-HYDRAULICS/N SX81-UP; B7W1-UP
Group No: 486-7651
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1661498 | 1 SEAL-LIP TYPE | 2 | |
| 5W2817 | 2 FITTING-GREASE | 3 | |
| 1238828 | 3 CONNECTOR AS | 3 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8T7876 | SEAL-O-RING | 1 | |
| 2286047 | CONNECTOR | 1 | |
| 1488444 | 4 TEE AS-SWIVEL | 2 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V9837 | TEE-SWIVEL | 1 | |
| 2258744 | 5 HOSE AS | 1 | |
| 2285621 | 6 BUSHING | 2 | |
| 2351758 | 7 HOSE AS | 2 | |
| 4171736 | 8 COVER | 2 | |
| 4172441 | 9 MOTOR & MANIFOLD GP-ROTATOR (VALVE) | 2 | |
| 4173610 | 10 PLATE-LOCK | 1 | |
| 4326246 | 11 HOSE AS | 1 | |
| 4483412 | 12 SPACER (14X28.6X35-MM THK) | 2 | |
| 4631056 | 13 BUMPER | 2 | |
| 4817654 | 14 PLATE | 2 | |
| 4854475 | 15 MANIFOLD | 2 | |
| 4863122 | 16 COVER | 1 | |
| 4863134 | 17 COVER | 1 | |
| 4863148 | 18 HOUSING AS-ROTATOR | 1 | |
| 8Y4499 | BOSS (M12X1.75X30-MM) | 8 | |
| 5218552 | 19 HOSE AS | 2 | |
| 1488345 | 20 CONNECTOR AS | 4 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8638 | CONNECTOR | 1 | |
| 1488372 | 21 ELBOW AS | 4 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8721 | ELBOW | 1 | |
| 1505968 | 22 TEE AS | 1 | |
| 4J5477 | SEAL-O-RING | 2 | |
| 6V9835 | TEE | 1 | |
| 1591119 | 23 LOCKWASHER | 8 | |
| 1984777 | 24 WASHER-HARD (11X25X10-MM THK) | 4 | |
| 2659596 | 25 WASHER-HARD (13.5X30X9-MM THK) | 8 | |
| 3E6910 | 26 BOLT-SOCKET HEAD (M12X1.75X70-MM) | 8 | |
| 3J1907 | 27 SEAL-O-RING | 2 | |
| 6V0852 | 28 CAP-DUST | 2 | |
| 6V3965 | 29 FITTING (QUICK DISCONNECT) | 2 | |
| 6V9830 | 30 CAP (ORFS) | 2 | |
| 8T0389 | 31 LOCKNUT (M10X1.5-THD) | 4 | |
| 8T4121 | 32 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4183 | 33 BOLT (M12X1.75X40-MM) | 8 | |
| 8T4185 | 34 BOLT (M10X1.5X50-MM) | 8 | |
| 8T4192 | 35 BOLT (M12X1.75X25-MM) | 4 | |
| 8T4223 | 36 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 8T4648 | 37 BOLT (M12X1.75X70-MM) | 4 | |
| 8T4910 | 38 BOLT (M12X1.75X60-MM) | 2 |
