System And Components
501-6650 ROTATOR GP-HYDRAULICS/N LX31-UP; SXD1-UP
Group No: 501-6650
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5W2817 | 1 FITTING-GREASE | 1 | |
| 6V0852 | 2 CAP-DUST | 2 | |
| 1238828 | 3 CONNECTOR AS | 2 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8T7876 | SEAL-O-RING | 1 | |
| 2286047 | CONNECTOR | 1 | |
| 1591119 | 4 LOCKWASHER | 4 | |
| 1703080 | 5 VALVE AS | 2 | |
| 0860972 | SEAL-O-RING | 1 | |
| 1773843 | 6 V-RING SEAL | 1 | |
| 1788598 | 7 HOSE AS | 1 | |
| 2372561 | 8 HOSE AS | 2 | |
| 2681604 | 9 CONNECTOR AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1049054 | CONNECTOR | 1 | |
| 3180334 | 10 MANIFOLD | 2 | |
| 4171736 | 11 COVER | 2 | |
| 4172441 | 12 MOTOR & MANIFOLD GP-ROTATOR (VALVE) | 1 | |
| 4173610 | 13 PLATE-LOCK | 1 | |
| 4631056 | 14 BUMPER | 2 | |
| 4817654 | 15 PLATE | 2 | |
| 5016648 | 16 COVER AS-ACCESS | 1 | |
| 5016649 | 17 HOUSING AS | 1 | |
| 1488328 | 18 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8633 | CONNECTOR | 1 | |
| 1488345 | 19 CONNECTOR AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8638 | CONNECTOR | 1 | |
| 3E6910 | 20 BOLT-SOCKET HEAD (M12X1.75X70-MM) | 4 | |
| 3J1907 | 21 SEAL-O-RING | 2 | |
| 6V3965 | 22 FITTING (QUICK DISCONNECT) | 2 | |
| 6V9830 | 23 CAP (ORFS) | 2 | |
| 8T0389 | 24 LOCKNUT (M10X1.5-THD) | 8 | |
| 8T4121 | 25 WASHER-HARD (11X21X2.5-MM THK) | 20 | |
| 8T4182 | 26 BOLT (M10X1.5X45-MM) | 4 | |
| 8T4192 | 27 BOLT (M12X1.75X25-MM) | 12 | |
| 8T4196 | 28 BOLT (M10X1.5X35-MM) | 4 | |
| 8T4198 | 29 BOLT (M10X1.5X100-MM) | 4 | |
| 8T4223 | 30 WASHER-HARD (13.5X25.5X3-MM THK) | 12 |
