System And Components
513-8356 ROTATOR GP-HYDRAULICS/N LX31-UP; SXD1-UP
Group No: 513-8356
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5138357 | 1 HOUSING AS-ROTATOR | 1 | |
| 5W2817 | 2 FITTING-GREASE | 1 | |
| 6V0852 | 3 CAP-DUST | 2 | |
| 1238828 | 4 CONNECTOR AS | 2 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8T7876 | SEAL-O-RING | 1 | |
| 2286047 | CONNECTOR | 1 | |
| 1703080 | 5 VALVE AS | 2 | |
| 0860972 | SEAL-O-RING | 1 | |
| 1773843 | 6 V-RING SEAL | 1 | |
| 1788598 | 7 HOSE AS | 1 | |
| 2681604 | 8 CONNECTOR AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1049054 | CONNECTOR | 1 | |
| 3180334 | 9 MANIFOLD | 2 | |
| 4171736 | 10 COVER | 2 | |
| 4172441 | 11 MOTOR & MANIFOLD GP-ROTATOR (VALVE) | 1 | |
| 4173610 | 12 PLATE-LOCK | 1 | |
| 4631056 | 13 BUMPER | 2 | |
| 4638733 | 14 COVER AS | 1 | |
| 4638737 | 15 COVER | 1 | |
| 4817654 | 16 PLATE | 2 | |
| 1488328 | 17 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8633 | CONNECTOR | 1 | |
| 1488345 | 18 CONNECTOR AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8638 | CONNECTOR | 1 | |
| 1591119 | 19 LOCKWASHER | 4 | |
| 1652750 | 20 HOSE AS | 2 | |
| 3E6910 | 21 BOLT-SOCKET HEAD (M12X1.75X70-MM) | 4 | |
| 3J1907 | 22 SEAL-O-RING | 2 | |
| 6V3965 | 23 FITTING (QUICK DISCONNECT) | 2 | |
| 6V9830 | 24 CAP (ORFS) | 2 | |
| 8T0389 | 25 LOCKNUT (M10X1.5-THD) | 8 | |
| 8T4121 | 26 WASHER-HARD (11X21X2.5-MM THK) | 24 | |
| 8T4136 | 27 BOLT (M10X1.5X25-MM) | 8 | |
| 8T4182 | 28 BOLT (M10X1.5X45-MM) | 4 | |
| 8T4192 | 29 BOLT (M12X1.75X25-MM) | 10 | |
| 8T4223 | 30 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 8T6466 | 31 BOLT (M10X1.5X60-MM) | 4 |
