System And Components
528-2431 ROTATOR GP-HYDRAULIC -SHEARS/N SX81-UP; B7W1-UP
Group No: 528-2431
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1488444 | 1 TEE AS-SWIVEL | 2 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V9837 | TEE-SWIVEL | 1 | |
| 1505968 | 2 TEE AS | 1 | |
| 4J5477 | SEAL-O-RING | 2 | |
| 6V9835 | TEE | 1 | |
| 5W2817 | 3 FITTING-GREASE | 1 | |
| 1238828 | 4 CONNECTOR AS | 3 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8T7876 | SEAL-O-RING | 1 | |
| 2286047 | CONNECTOR | 1 | |
| 1505005 | 5 HOSE AS | 1 | |
| 2172088 | 6 HOSE AS | 1 | |
| 2681604 | 7 CONNECTOR AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1049054 | CONNECTOR | 1 | |
| 3180334 | 8 MANIFOLD | 2 | |
| 3685418 | 9 HOSE AS | 1 | |
| 3685419 | 10 HOSE AS | 1 | |
| 4171736 | 11 COVER | 2 | |
| 4172441 | 12 MOTOR & MANIFOLD GP-ROTATOR (VALVE) | 2 | |
| 4631056 | 13 BUMPER | 2 | |
| 4638733 | 14 COVER AS | 2 | |
| 4817654 | 15 PLATE | 2 | |
| 5282432 | 16 HOUSING AS | 1 | |
| 5285039 | 17 HOSE AS | 2 | |
| 1488328 | 18 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8633 | CONNECTOR | 1 | |
| 1488345 | 19 CONNECTOR AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8638 | CONNECTOR | 1 | |
| 1488370 | 20 ELBOW AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9851 | ELBOW | 1 | |
| 1488372 | 21 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8721 | ELBOW | 1 | |
| 1591119 | 22 LOCKWASHER | 8 | |
| 1645557 | 23 CONNECTOR AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 5I4370 | CONNECTOR | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1984777 | 24 WASHER-HARD (11X25X10-MM THK) | 4 | |
| 3E6910 | 25 BOLT-SOCKET HEAD (M12X1.75X70-MM) | 8 | |
| 3J1907 | 26 SEAL-O-RING | 2 | |
| 6V0852 | 27 CAP-DUST | 2 | |
| 6V3965 | 28 FITTING (QUICK DISCONNECT) | 2 | |
| 6V9830 | 29 CAP (ORFS) | 2 | |
| 8T0389 | 30 LOCKNUT (M10X1.5-THD) | 4 | |
| 8T4121 | 31 WASHER-HARD (11X21X2.5-MM THK) | 12 | |
| 8T4185 | 32 BOLT (M10X1.5X50-MM) | 8 | |
| 8T4192 | 33 BOLT (M12X1.75X25-MM) | 12 | |
| 8T4196 | 34 BOLT (M10X1.5X35-MM) | 4 | |
| 8T4223 | 35 WASHER-HARD (13.5X25.5X3-MM THK) | 12 |
