System And Components
525-3702 WIRING GP-CONSOLE -SIDEPART OF 515-1822 CAB AR
Group No: 525-3702
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 2 | |
| 7K1181 | 2 STRAP-CABLE | 4 | |
| 1311424 | 3 SEAL | 1 | |
| 1428858 | 4 SWITCH AS-START (KEY) | 1 | |
| 1671530 | NUT (1-32-THD) | 1 | |
| 1571997 | 5 SPACER (4.34X15.88X6.34-MM THK) | 2 | |
| 1690587 | 6 SWITCH AS-ROCKER (HORN) | 1 | |
| 1690590 | 7 SWITCH AS-ROCKER (FLOODLIGHT, REAR) | 2 | |
| 1690592 | 8 SWITCH AS-ROCKER (FLOODLIGHTS, FRONT) | 1 | |
| 1690597 | 9 SWITCH AS-ROCKER (SIDESHIFT, LOCK-UNLOCK) | 1 | |
| 1117899 | GASKET | 1 | |
| 1919104 | 10 FILM-INSTRUCTION (START SWITCH) | 1 | |
| 2236539 | 11 MODULE GP-WARNING INDICATOR (WITH ALARM) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 10 | |
| 8T8737 | PLUG-SEAL | 2 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 2324706 | GASKET | 1 | |
| 2504673 | 13 SWITCH-TOGGLE (FOG LIGHT) | 1 | |
| 2872801 | 15 GAUGE-TEMPERATURE (ENGINE COOLANT) | 1 | |
| 2872803 | 16 GAUGE-LIQUID LEVEL (FUEL) | 1 | |
| 4440154 | 17 METER AS | 1 | |
| 5243240 | 18 HARNESS AS-CONSOLE | 1 | |
| 4P8134 | 19 CLIP (LADDER) | 3 | |
| 8T2659 | 20 LOCKNUT (M4X0.7-THD) | 2 | |
| 8T4133 | 21 NUT (M10X1.5-THD) | 3 | |
| 8T4191 | 22 BOLT (M10X1.5X16-MM) | 3 |
