Assembly
100%

535-8570 BUCKET GP -SHOVEL2682-MM (105.6-IN) WIDE X 8.6-CU M (11.2-CU YD) CAPACITY. C-70 ADAPTERS, QTY OF 5

Group No: 535-8570
Part NumberPart NameQty
7X32291 FILM-IDENTIFICATION (LIFT EYE, TIE-DOWN LOCATION)4
31256942 SETSCREW (1/4-20X0.25-IN)1
41523533 PROTECTOR2
43310564 SHROUD AS (RH)1
36391094A SLEEVE2
39527974B RETAINER-LOCK2
43310575 SHROUD AS (LH)1
36391095A SLEEVE2
39527975B RETAINER-LOCK2
44782356 KIT-RETAINER2
41523546A PIN2
41536516B RETAINER4
45990167 LUG4
48371448 SHROUD AS-EDGE (CENTER)2
36391098A SLEEVE2
39527978B RETAINER-LOCK2
53852899 BUCKET AS (SHOVEL)1
