System And Components
472-4323 BUCKET GP -SHOVEL4361-MM (171.7-IN) WIDE X 18-CU M (23.5-CU YD) CAPACITY. C-85 ADAPTERS, QTY OF 6
Group No: 472-4323
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3125694 | 1 SETSCREW (1/4-20X0.25-IN) | 1 | |
| 4153651 | 2 RETAINER | 8 | |
| 4174638 | 3 SHROUD AS (LH) | 2 | |
| 3639109 | 3A SLEEVE | 2 | |
| 3952797 | 3B RETAINER-LOCK | 2 | |
| 4174639 | 4 SHROUD AS (RH) | 2 | |
| 3639109 | 4A SLEEVE | 2 | |
| 3952797 | 4B RETAINER-LOCK | 2 | |
| 4174640 | 5 SHROUD AS (CENTER) | 1 | |
| 3639109 | 5A SLEEVE | 2 | |
| 3952797 | 5B RETAINER-LOCK | 2 | |
| 4308480 | 6 PROTECTOR | 2 | |
| 4308484 | 7 PIN-RETAINER | 4 | |
| 4319196 | 8 BUSHING | 2 | |
| 4387050 | 9 BUSHING | 2 | |
| 4599016 | 10 LUG | 5 | |
| 4771028 | 11 BUCKET AS (WEAR) | 1 | |
| 4510428 | 13 ADAPTER AS | 4 | |
| 2287089 | SEAL-O-RING | 1 | |
| 4510427 | ADAPTER | 1 | |
| 4515682 | SEAL | 1 | |
| 4982086 | 14 PLATE-COVER | 2 | |
| 6V9829 | 15 CAP (ORFS) | 4 | |
| 7X2553 | 16 BOLT (M16X2X40-MM) | 6 | |
| 9X8257 | 17 WASHER (17.5X30X3.5-MM THK) | 6 |
