System And Components
484-4207 BUCKET GP -SHOVEL4440-MM (174.8-IN) WIDE X 22-CU M (28.8-CU YD) CAPACITY. C-95 ADAPTERS, QTY OF 6
Group No: 484-4207
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3125694 | 1 SETSCREW (1/4-20X0.25-IN) | 1 | |
| 4153651 | 2 RETAINER | 8 | |
| 4308476 | 3 BUSHING | 2 | |
| 4308477 | 4 BUSHING | 2 | |
| 4308480 | 5 PROTECTOR | 2 | |
| 4308484 | 6 PIN-RETAINER | 4 | |
| 4599016 | 7 LUG | 5 | |
| 4634156 | 8 SHROUD AS (CENTER) | 1 | |
| 3639109 | 8A SLEEVE | 2 | |
| 3952797 | 8B RETAINER-LOCK | 2 | |
| 4634158 | 9 SHROUD AS (LH) | 2 | |
| 3639109 | 9A SLEEVE | 2 | |
| 3952797 | 9B RETAINER-LOCK | 2 | |
| 4634160 | 10 SHROUD AS (RH) | 2 | |
| 3639109 | 10A SLEEVE | 2 | |
| 3952797 | 10B RETAINER-LOCK | 2 | |
| 4844206 | 11 BUCKET AS (WEAR) | 1 | |
| 9X8257 | 12 WASHER (17.5X30X3.5-MM THK) | 6 | |
| 4510428 | 13 ADAPTER AS | 4 | |
| 2287089 | SEAL-O-RING | 1 | |
| 4510427 | ADAPTER | 1 | |
| 4515682 | SEAL | 1 | |
| 4982086 | 14 PLATE-COVER | 2 | |
| 6V0826 | 15 GROMMET | 4 | |
| 6V9829 | 16 CAP (ORFS) | 4 | |
| 7X2553 | 17 BOLT (M16X2X40-MM) | 6 | |
| 8T1889 | 18 CLIP (SLOT) | 4 | |
| 8T1890 | 19 CLIP (TAB) | 4 | |
| 8T4121 | 20 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4195 | 21 BOLT (M10X1.5X30-MM) | 4 |
