Assembly
100%

504-9719 BUCKET GP -SHOVEL4765-MM (187.6-IN) WIDE X 34-CU M (44.5-CU YD) CAPACITY, W900 NOSE STATIONS, QTY OF 6

Group No: 504-9719
Part NumberPart NameQty
9X82571 WASHER (17.5X30X3.5-MM THK)6
42875732 BUSHING2
44417103 SHROUD2
44417476 KIT-RETAINER7
44417497 KIT-RETAINER2
45104289 ADAPTER AS4
2287089SEAL-O-RING1
4510427ADAPTER1
4515682SEAL1
485163810 SHROUD (LH)2
485163911 SHROUD (RH)2
485164012 SHROUD (CENTER)1
489637913 SHROUD (LH, LOWER)1
489638014 SHROUD (RH, LOWER)1
498208616 PLATE-COVER2
504972017 BUCKET AS (WEAR)1
505237918 BUSHING2
506398619 FILM GP1
312569420 SETSCREW (1/4-20X0.25-IN)1
6V982921 CAP (ORFS)4
7X255322 BOLT (M16X2X40-MM)6
