System And Components
505-3733 BUCKET GP -SHOVEL4765-MM (187.6-IN) WIDE X 31-CU M (40.5-CU YD) CAPACITY. W900 NOSE STATIONS, QUANTITY OF 6
Group No: 505-3733
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X8257 | 1 WASHER (17.5X30X3.5-MM THK) | 6 | |
| 4287573 | 2 BUSHING | 2 | |
| 4441710 | 3 SHROUD | 2 | |
| 4441719 | 4 TIP-PENETRATION | 6 | |
| 4441729 | 5 KIT-RETAINER | 6 | |
| 4620763 | PLUG AS | 1 | |
| 4441747 | 6 KIT-RETAINER | 7 | |
| 4441749 | 7 KIT-RETAINER | 2 | |
| 4441754 | 8 KIT-RETAINER | 6 | |
| 4620764 | PLUG AS | 1 | |
| 4510428 | 9 ADAPTER AS | 4 | |
| 2287089 | SEAL-O-RING | 1 | |
| 4510427 | ADAPTER | 1 | |
| 4515682 | SEAL | 1 | |
| 4851638 | 10 SHROUD (LH) | 2 | |
| 4851639 | 11 SHROUD (RH) | 2 | |
| 4851640 | 12 SHROUD (CENTER) | 1 | |
| 4896379 | 13 SHROUD (LH, LOWER) | 1 | |
| 4896380 | 14 SHROUD (RH, LOWER) | 1 | |
| 4921978 | 15 COUPLER | 6 | |
| 4982086 | 16 PLATE-COVER | 2 | |
| 5052379 | 17 BUSHING | 2 | |
| 5053734 | 18 BUCKET AS (WEAR) | 1 | |
| 5076884 | 19 FILM GP | 1 | |
| 1508896 | 19A FILM-NOTICE (LIFT EYE LOCATION) | 4 | |
| 1565762 | 19B FILM-INFORMATION (TIE-DOWN LOCATION) | 4 | |
| 3125694 | 20 SETSCREW (1/4-20X0.25-IN) | 1 | |
| 6V9829 | 21 CAP (ORFS) | 4 | |
| 7X2553 | 22 BOLT (M16X2X40-MM) | 6 |
