Assembly
100%

508-9783 BUCKET GP -SHOVEL4765-MM (187.6-IN) WIDE X 25-CU M (32.7-CU YD) CAPACITY. W950 NOSE STATIONS, QUANTITY OF 6

Group No: 508-9783
Part NumberPart NameQty
50897841 BUCKET AS (WEAR)1
42875732 BUSHING2
44416943 SHROUD (CENTER)1
44416954 SHROUD (LH)2
44416965 SHROUD (RH)2
44417116 SHROUD (WING)2
44417477 KIT-RETAINER7
44417498 KIT-RETAINER2
45104289 ADAPTER AS4
2287089SEAL-O-RING1
4510427ADAPTER1
4515682SEAL1
498208610 PLATE-COVER2
505237911 BUSHING2
508978512 FILM GP1
150889612A FILM-NOTICE (LIFT EYE LOCATION)4
156576212B FILM-INFORMATION (TIE-DOWN LOCATION)4
9X825713 WASHER (17.5X30X3.5-MM THK)6
312569414 SETSCREW (1/4-20X0.25-IN)1
444171015 SHROUD2
6V982916 CAP (ORFS)4
7X255317 BOLT (M16X2X40-MM)6
