512-3821 FRAME GP-TRACK ROLLERPART OF 512-3820 UNDERCARRIAGE AR

Group No: 512-3821
Part NumberPart NameQty
10641751 BOLT (M20X2.5X60-MM)12
19847812 WASHER-HARD (22X40X10-MM THK)12
35624593 BUSHING4
36612814 PLATE2
51238155 FRAME AS-FRONT2
51238226 FRAME GP-UNDERCARRIAGE1
5123823FRAME AS-UNDERCARRIAGE (LH)1
5123824FRAME AS-UNDERCARRIAGE (RH)1
51239287 MOUNTING GP-SUSPENSION2
35624597A BUSHING2
5123927TUBE1
53635498 ROLLER GP-TRACK (TRIPLE FLANGE)10
7X05649 WASHER-HARD (20X51X3-MM THK)8
7X056710 WASHER-HARD (20X51X1-MM THK)68
8T422411 WASHER-HARD (8.8X16X2-MM THK)2
8T490812 BOLT (M8X1.25X25-MM)2
8T543913 WASHER-HARD (21.5X45X6-MM THK)20
8T643014 BOLT (M20X2.5X50-MM)20
