System And Components
556-6534 RADIATOR & HYD OIL COOLER GPS/N FEY1-UP
Group No: 556-6534 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4195 | 1 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4200 | 2 BOLT (M8X1.25X16-MM) | 7 | |
| 8T4908 | 3 BOLT (M8X1.25X25-MM) | 4 | |
| 3S2093 | 4 STRAP-CABLE | 1 | |
| 5P4116 | 5 WASHER-HARD (8.8X20.5X2-MM THK) | 10 | |
| 7X7729 | 6 WASHER (11X25X3-MM THK) | 10 | |
| 8T4121 | 7 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4136 | 8 BOLT (M10X1.5X25-MM) | 3 | |
| 8T4137 | 9 BOLT (M10X1.5X20-MM) | 6 | |
| 8T4224 | 10 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 8T6703 | 11 CLAMP-HOSE | 4 | |
| 0964035 | 12 CLIP | 3 | |
| 0965819 | 13 TANK AS-COOLANT (RECOVERY) | 1 | |
| 1713369 | CAP AS (COOLANT RECOVERY) | 1 | |
| 1719077 | 14 BAND | 1 | |
| 3057664 | 15 BRACKET AS | 1 | |
| 5220896 | 16 BOLT-HEAD (M16X2X100-MM) | 4 | |
| 1786450 | 17 SPACER (17X35X30-MM THK) | 4 | |
| 3623147 | 18 CLIP (LOOP) | 1 | |
| 5249955 | 19 GUARD AS | 1 | |
| 5480129 | 20 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 4 | |
| 5480130 | 21 HOSE-UPPER RADIATOR | 1 | |
| 5480131 | 22 HOSE-RADIATOR (LOWER) | 1 | |
| 5485561 | 23 BAFFLE AS | 1 | |
| 5535748 | 24 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 5570253 | 25 BAFFLE AS | 1 | |
| 5573514 | 26 LINER | 1 | |
| 5573515 | 27 LINER | 1 | |
| 5573613 | 28 LINER-BOTTOM | 1 | |
| 5573772 | 29 RADIATOR & HYD OIL COOLER GP | 1 | |
| 5573806 | 30 LINER | 1 | |
| 7Y1976 | 31 HOSE-WATER (201-CM) | ||
| 7Y1976 | 31A HOSE-WATER (38-CM) | ||
| 5P9909 | 32 SEAL (0.1-M) | ||
| 5P5649 | 33 SEAL-BULK (0.1-M EACH) | ||
| 3485409 | 34 SEAL (10-DM) | ||
| 1570670 | 35 CAP-DUST | 1 | |
| 1549023 | 36 VALVE-SAMPLING | 1 | |
| 6V9027 | 37 SEAL-O-RING | 1 | |
| 6V5217 | 38 BOLT (M8X1.25X20-MM) | 5 |
