System And Components
498-5209 HOUSING GP-SHEARS/N SX21-UP; LNP1-UP
Group No: 498-5209
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2825965 | 1 GEAR & BEARING GP | 1 | |
| 5W2817 | FITTING-GREASE | 2 | |
| 2301621 | SEAL (315-CM) | ||
| 5429546 | 2 SWIVEL GP | 1 | |
| 5W2817 | 3 FITTING-GREASE | 5 | |
| 1238828 | 4 CONNECTOR AS | 2 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8T7876 | SEAL-O-RING | 1 | |
| 2286047 | CONNECTOR | 1 | |
| 1690901 | 5 HOSE AS | 1 | |
| 1703080 | 6 VALVE AS | 2 | |
| 0860972 | SEAL-O-RING | 1 | |
| 4335455 | 7 PIN-CYLINDER | 1 | |
| 4335456 | 8 PLATE-RETAINING | 4 | |
| 4335457 | 9 CYLINDER & VALVE GP | 1 | |
| 4882896 | 10 PLATE | 1 | |
| 4890232 | 11 MOTOR GP-GEROTOR | 1 | |
| 4989684 | 12 JAW AS | 1 | |
| 4335460 | 12A BEARING-SLEEVE | 2 | |
| 4989685 | 12B BEARING-SLEEVE | 2 | |
| 4989818 | 13 HOUSING AS | 1 | |
| 4989830 | PLATE-WEAR | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 7 | |
| 5585895 | PLATE | 1 | |
| 1946246 | INSERT | 1 | |
| 4989886 | 14 SHIM (0.1-MM THK) | 2 | |
| 4991723 | 15 BEARING | 2 | |
| 4991724 | 16 BUSHING | 1 | |
| 4991725 | 17 PIN-LOCK | 4 | |
| 4991726 | 18 PIN | 1 | |
| 4991727 | 19 COVER | 1 | |
| 4991728 | 20 NUT | 1 | |
| 4991729 | 21 PIN-CYLINDER | 1 | |
| 4991733 | 22 MANIFOLD | 2 | |
| 4991734 | 23 COVER | 1 | |
| 4991735 | 24 HOSE AS | 1 | |
| 4991736 | 25 HOSE AS | 1 | |
| 4991750 | 26 EDGE GP-CUTTING | 1 | |
| 4993531 | 27 SHIM (0.1-MM THK) | 2 | |
| 5222333 | 28 HOSE AS | 1 | |
| 5222441 | 29 HOSE AS | 1 | |
| 5429576 | 30 MANIFOLD AS | 1 | |
| 0959804 | 31 BOLT-SOCKET HEAD (M12X1.75X110-MM) | 12 | |
| 1488327 | 32 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488336 | 33 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488367 | 34 ELBOW AS | 2 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 1488378 | 35 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488392 | 36 ELBOW AS | 2 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 6V9853 | ELBOW | 1 | |
| 1504044 | 37 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T1779 | CONNECTOR | 1 | |
| 1591119 | 38 LOCKWASHER | 18 | |
| 1591121 | 39 LOCKWASHER | 2 | |
| 1600018 | 40 SCREW-FLAT HEAD (M12X1.75X45-MM) | 8 | |
| 1984780 | 41 WASHER-HARD (17.5X32X8-MM THK) | 4 | |
| 1P3702 | 42 SEAL-RECTANGULAR | 2 | |
| 1P3703 | 43 SEAL-RECTANGULAR | 4 | |
| 2416185 | 44 PLUG AS | 4 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 5P9436 | PLUG | 1 | |
| 3E6910 | 45 BOLT-SOCKET HEAD (M12X1.75X70-MM) | 4 | |
| 4D1322 | 46 RING-RETAINING | 8 | |
| 6V8399 | 47 SEAL-O-RING | 4 | |
| 7X2556 | 48 BOLT (M16X2X100-MM) | 32 | |
| 8C8407 | 49 BOLT (M12X1.75X260-MM) | 4 | |
| 8T0273 | 50 BOLT-SOCKET HEAD (M12X1.75X40-MM) | 2 | |
| 8T0439 | 51 BOLT-SOCKET HEAD (M16X2X30-MM) | 2 | |
| 8T4121 | 52 WASHER-HARD (11X21X2.5-MM THK) | 15 | |
| 8T4139 | 53 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4140 | 54 BOLT (M16X2X60-MM) | 4 | |
| 8T4182 | 55 BOLT (M10X1.5X45-MM) | 8 | |
| 8T4195 | 56 BOLT (M10X1.5X30-MM) | 7 | |
| 8T4223 | 57 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T9403 | 58 FLANGE-HALF | 4 | |
| 9X8257 | 59 WASHER (17.5X30X3.5-MM THK) | 32 |
