System And Components
486-5177 SWITCH GP-SHUTDOWN -PLCPART OF 498-8801 MOUNTING GP-SWITCH
Group No: 486-5177
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E9259 | 1 TERMINAL AS | 1 | |
| 5C7423 | 2 SCREW (M6X1X16-MM) | 4 | |
| 7X6315 | 3 STRAP AS-GROUND | 1 | |
| 2L8075 | TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW) | 1 | |
| 2L8078 | TERMINAL-RING (14-GA TO 16-GA, 5/16-IN SCREW) | 1 | |
| 5P6006 | TUBE-HEAT SHRINK (9.52-MM DIA)(0.1-M) | ||
| 0898034 | 4 SCREW-BUTTON HEAD | 4 | |
| 1003095 | 5 WASHER | 2 | |
| 1551996 | 6 CLIP | 2 | |
| 1552001 | 7 RETAINER | 2 | |
| 3055121 | 8 CLAMP | 2 | |
| 3187612 | 9 MODULE (TERMINAL, ELECTRONIC MODULE) | 1 | |
| 3187613 | 10 MODULE (TERMINAL, POWER MODULE) | 1 | |
| 3214472 | 11 MODULE-INTERFACE | 1 | |
| 3214473 | 12 MODULE-POWER | 1 | |
| 3214474 | 13 MODULE | 1 | |
| 3187723 | 14 RAIL (1-M) | ||
| 3981724 | 15 CLIP | 1 | |
| 9X8256 | 16 WASHER (6.6X12X2-MM THK) | 10 | |
| 4733361 | 17 CONNECTOR AS | 1 | |
| 4820222 | 18 BEAD | 1 | |
| 4820223 | 19 CONNECTOR | 1 | |
| 4995799 | 20 FASTENER | 2 | |
| 9B7233 | 21 LOCKWASHER | 3 | |
| 8T0267 | 22 BOLT-SOCKET HEAD (M6X1X12-MM) | 4 | |
| 5010776 | 23 PLATE AS | 1 | |
| 5010777 | 24 PLATE AS | 1 | |
| 6V8225 | NUT (M6X1-THD) | 2 | |
| 6V5698 | 25 SCREW-BUTTON HEAD (M4X0.7X10-MM) | 7 | |
| 3C6969 | 26 NUT (M3X0.5-THD) | 2 | |
| 5019212 | 27 CABLE AS | 1 | |
| 0965962 | 28 WASHER-HARD (3.4X7X0.8-MM THK) | 4 | |
| 0966166 | 29 WASHER-HARD (4.5X9X1-MM THK) | 4 | |
| 1554098 | 30 SCREW-BUTTON HEAD (M3X0.5X1-MM) | 2 | |
| 3445673 | 31 NUT (M6X1-THD) | 4 |
