System And Components
533-3342 LINES GP-WATER -VENTS/N ZLK1-UP
Group No: 533-3342
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0307942 | 1 ELBOW | 1 | |
| 0307947 | 2 ADAPTER-ELBOW | 2 | |
| 0530700 | 3 TEE-SWIVEL (FLARED) | 1 | |
| 1360853 | 4 ADAPTER | 1 | |
| 1503050 | 5 CONNECTOR AS | 1 | |
| 6V7486 | CONNECTOR | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1965052 | 6 CLIP (SLOT) | 1 | |
| 1965053 | 7 CLIP (TAB) | 1 | |
| 2006345 | 8 SADDLE-MOUNTING (DUAL SWIVEL) | 1 | |
| 2501467 | 9 CONNECTOR AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 7I8663 | CONNECTOR | 1 | |
| 2684045 | 10 CONNECTOR | 3 | |
| 3260308 | 11 CONNECTOR | 1 | |
| 3378766 | 12 CONNECTOR | 2 | |
| 3445675 | 13 NUT (M10X1.5-THD) | 1 | |
| 4264163 | 14 REDUCER (37-DEG) | 1 | |
| 4667547 | 15 PLATE AS | 1 | |
| 1F7958 | NUT-FULL (1/2-13-THD) | 1 | |
| 9S8752 | NUT-FULL (3/8-16-THD) | 1 | |
| 5333344 | 16 TUBE AS | 1 | |
| 5333345 | 17 TUBE AS | 1 | |
| 5459564 | 18 HOSE AS | 1 | |
| 5459565 | 19 HOSE AS | 1 | |
| 5488138 | 20 HOSE AS | 1 | |
| 5678772 | 21 HOSE AS | 1 | |
| 0S0509 | 22 BOLT (3/8-16X0.75-IN) | 1 | |
| 1P4278 | 23 CLAMP-HOSE | 6 | |
| 2T0130 | 24 HOSE-RADIATOR | 1 | |
| 3J1907 | 25 SEAL-O-RING | 9 | |
| 3K0360 | 26 SEAL-O-RING | 1 | |
| 4D7388 | 27 CLIP | 2 | |
| 5D1026 | 28 CLAMP-BAND | 1 | |
| 5M2894 | 29 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 5P2230 | 30 CLAMP-HOSE | 2 | |
| 5V9221 | 31 SPACER (13.8X25X25-MM THK) | 1 | |
| 6D3479 | 32 CLIP (LOOP) | 2 | |
| 6K8178 | 33 CLIP (LOOP) | 3 | |
| 6V1323 | 34 ELBOW | 1 | |
| 6V1867 | 35 CLIP (SLOT) | 1 | |
| 6V1868 | 36 CLIP (TAB) | 1 | |
| 6V1869 | 37 GROMMET (65-MM ID) | 1 | |
| 6V6609 | 38 SEAL-O-RING | 2 | |
| 6V8076 | 39 ELBOW | 2 | |
| 6V9027 | 40 SEAL-O-RING | 1 | |
| 6V9996 | 41 ELBOW | 1 | |
| 7J0204 | 42 SEAL-O-RING | 2 | |
| 7K1181 | 43 STRAP-CABLE | 2 | |
| 7M8485 | 44 SEAL-O-RING | 1 | |
| 7X0293 | 45 BOLT (3/8-16X4.75-IN) | 1 | |
| 7X0440 | 46 BOLT (5/16-18X1.75-IN) | 2 | |
| 8C3051 | 47 ADAPTER | 1 | |
| 8F8151 | 48 VALVE-SHUTOFF | 1 | |
| 8T4121 | 49 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4136 | 50 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4137 | 51 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4186 | 52 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4223 | 53 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4224 | 54 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4896 | 55 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 8T4984 | 56 CLAMP-HOSE | 7 | |
| 8T4985 | 57 CLAMP-HOSE | 7 | |
| 8T8917 | 58 BOLT (1/2-13X1.25-IN) | 1 | |
| 9M4136 | 59 SPACER (0.438X0.75X0.5-IN THK) | 3 | |
| 9S4185 | 60 PLUG (3/4-16-THD) | 2 | |
| 9U6999 | 61 ELBOW AS | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 0344202 | ELBOW | 1 | |
| 3718946 | 62 HOSE (11-CM) | ||
| 5P0767 | 63 HOSE (32-CM) | ||
| 3718949 | 64 HOSE (16-CM EACH) | ||
| 3718094 | 65 HOSE (145-CM) | ||
| 5P1465 | 66 HOSE (70-CM) | ||
| 5P1465 | 66A HOSE (84-CM) | ||
| 5P1465 | 66B HOSE (36-CM) |
