533-3343 LINES GP-WATER -VENTS/N ZLK1-UP

Group No: 533-3343

Part Number	Part Name	Qty
0307947	1 ADAPTER-ELBOW	1
1360853	2 ADAPTER	1
1503050	3 CONNECTOR AS	1
6V7486	CONNECTOR	1
7M8485	SEAL-O-RING	1
1782500	4 FLANGE	1
1965052	5 CLIP (SLOT)	1
1965053	6 CLIP (TAB)	1
2006345	7 SADDLE-MOUNTING (DUAL SWIVEL)	1
2636342	8 CLIP	1
2684045	9 CONNECTOR	3
3260308	10 CONNECTOR	1
3378766	11 CONNECTOR	2
3419211	12 GASKET	2
3445675	13 NUT (M10X1.5-THD)	1
3603692	14 PLUG (9/16-18-THD)	1
4667547	15 PLATE AS	1
1F7958	NUT-FULL (1/2-13-THD)	1
9S8752	NUT-FULL (3/8-16-THD)	1
5333344	16 TUBE AS	1
5333346	17 HOSE AS	1
5333347	18 TUBE AS	1
0S0509	19 BOLT (3/8-16X0.75-IN)	1
0S1594	20 BOLT (3/8-16X1-IN)	4
1P4278	21 CLAMP-HOSE	6
2T0130	22 HOSE-RADIATOR	1
3J1907	23 SEAL-O-RING	8
3K0360	24 SEAL-O-RING	1
4D7388	25 CLIP	2
5D1026	26 CLAMP-BAND	1
5M2894	27 WASHER-HARD (10.2X18.5X2.5-MM THK)	5
5P2230	28 CLAMP-HOSE	2
6D3479	29 CLIP (LOOP)	1
6V1323	30 ELBOW	1
6V1867	31 CLIP (SLOT)	1
6V1868	32 CLIP (TAB)	1
6V1869	33 GROMMET (65-MM ID)	1
6V6609	34 SEAL-O-RING	2
6V8076	35 ELBOW	2
7J0204	36 SEAL-O-RING	2
7K1181	37 STRAP-CABLE	2
7N7878	38 PLATE-COVER	1
7X0440	39 BOLT (5/16-18X1.75-IN)	2
8F8151	40 VALVE-SHUTOFF	1
8L3282	41 CONNECTOR (37-DEG)	1
8T4121	42 WASHER-HARD (11X21X2.5-MM THK)	4
8T4136	43 BOLT (M10X1.5X25-MM)	2
8T4186	44 BOLT (M10X1.5X40-MM)	1
8T4223	45 WASHER-HARD (13.5X25.5X3-MM THK)	1
8T4224	46 WASHER-HARD (8.8X16X2-MM THK)	2
8T4984	47 CLAMP-HOSE	7
8T4985	48 CLAMP-HOSE	7
8T8917	49 BOLT (1/2-13X1.25-IN)	1
9M4136	50 SPACER (0.438X0.75X0.5-IN THK)	2
9S4185	51 PLUG (3/4-16-THD)	2
9U6999	52 ELBOW AS	1
7M8485	SEAL-O-RING	1
0344202	ELBOW	1
5P0767	53 HOSE (30-CM)
3718949	54 HOSE (15-CM EACH)
3718946	55 HOSE (11-CM)
3718094	56 HOSE (151-CM)
5P1465	57 HOSE (70-CM)
5P1465	57A HOSE (36-CM)
5P1465	57B HOSE (84-CM)
