529-0398 RADIATOR GPS/N ZLK1-UP

Group No: 529-0398

Part Number	Part Name	Qty
1P2807	1 FILM-IDENTIFICATION (LIFT EYE LOCATION)	2
7K3176	2 COUPLING AS-REFRIGERANT (SELF-SEALING)	2
7K3304	3 NUT-JAM (1-20-THD)	2
8C4427	4 PLUNGER (PLASTIC)	2
1944122	5 ADAPTER	2
1964687	6 CLAMP	4
2672244	7 HOSE AS	1
2672245	8 HOSE AS	1
2679816	9 BRACE	2
3787590	10 COIL AS	1
4979634	11 BRACKET	1
4979635	12 BRACKET	1
5184897	13 ADAPTER	1
5247392	14 COOLER-FUEL	2
5296148	15 PLATE	2
5333332	16 AFTERCOOLER GP-AIR	1
5333336	17 SEAL AS (LH)	1
1072207	RIVET-POP	11
5333337	18 SEAL AS (RH)	1
1072207	RIVET-POP	11
5499261	19 COOLER AS (HYDRAULIC)	1
5499262	20 MOUNT AS	1
5501219	21 BRACKET AS	2
5501286	22 TUBE AS	2
5502516	23 SHROUD GP-RADIATOR (AIR)	1
5504962	24 BRACKET AS	1
0307972	25 ELBOW	1
0L2070	26 BOLT (3/8-16X2.25-IN)	4
0S1588	27 BOLT (3/8-16X1.25-IN)	4
0S1594	28 BOLT (3/8-16X1-IN)	52
0S1617	29 BOLT (5/16-18X0.75-IN)	6
0S1618	30 BOLT (5/16-18X1-IN)	8
1920089	31 BOLT-SOCKET HEAD (1/4-20X1-IN)	2
1F7958	32 NUT-FULL (1/2-13-THD)	8
2088469	33 LOCKNUT (M6X1-THD)	4
2679817	34 BRACE	1
2725629	35 GUARD GP-FAN	1
3511285	36 RADIATOR GP	1
3B4504	37 LOCKWASHER	2
3E9860	38 LOCKNUT (5/16-18-THD)	2
3E9865	39 LOCKNUT (1/4-20-THD)	2
3K6060	40 LOCKNUT (3/8-16-THD)	4
5333338	41 SEAL AS (TOP)	1
1072207	RIVET-POP	8
5333339	42 SEAL AS (BOTTOM)	1
1072207	RIVET-POP	8
5M2894	43 WASHER-HARD (10.2X18.5X2.5-MM THK)	72
5P0537	44 WASHER-HARD (7.2X14.5X2-MM THK)	2
5P8245	45 WASHER-HARD (13.5X25.5X3-MM THK)	4
8T6974	46 BOLT (M6X1X80-MM)	4
7R7951	47 PLATE	4
8T1889	48 CLIP (SLOT)	4
8T1890	49 CLIP (TAB)	4
9F6580	50 BOLT (1/4-20X1.125-IN)	2
9M1974	51 WASHER-HARD (8.8X16X2-MM THK)	16
9R8537	52 SOCKET-LATCH	2
9S8750	53 NUT-FULL (1/4-20-THD)	2
9S8752	54 NUT-FULL (3/8-16-THD)	12
9X7380	55 SEAL-O-RING	1
9X7381	56 SEAL-O-RING	1
9X7383	57 SEAL-O-RING	2
