System And Components
529-0399 RADIATOR GP -AFTERCOOLERS/N ZLK1-UP
Group No: 529-0399
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P2807 | 1 FILM-IDENTIFICATION (LIFT EYE LOCATION) | 2 | |
| 7K3176 | 2 COUPLING AS-REFRIGERANT (SELF-SEALING) | 2 | |
| 7K3304 | 3 NUT-JAM (1-20-THD) | 2 | |
| 8C4427 | 4 PLUNGER | 2 | |
| 1944122 | 5 ADAPTER | 2 | |
| 1964687 | 6 CLAMP | 4 | |
| 2672244 | 7 HOSE AS | 1 | |
| 2672245 | 8 HOSE AS | 1 | |
| 3787590 | 9 COIL AS | 1 | |
| 4979634 | 10 BRACKET | 1 | |
| 4979635 | 11 BRACKET | 1 | |
| 5184897 | 12 ADAPTER | 1 | |
| 5247392 | 13 COOLER-FUEL | 2 | |
| 5249180 | 14 BRACE | 1 | |
| 5296144 | 15 RADIATOR GP | 1 | |
| 5797040 | 16 PLATE AS | 1 | |
| 5333332 | 17 AFTERCOOLER GP-AIR | 1 | |
| 5333334 | 18 PLATE AS | 1 | |
| 5333336 | 19 SEAL AS (LH) | 1 | |
| 5333337 | 20 SEAL AS (RH) | 1 | |
| 1072207 | RIVET-POP | 11 | |
| 5499261 | 21 COOLER AS (HYDRAULIC) | 1 | |
| 5499262 | 22 MOUNT AS | 1 | |
| 5501219 | 23 BRACKET AS | 2 | |
| 5501286 | 24 TUBE AS | 2 | |
| 5502516 | 25 SHROUD GP-RADIATOR (AIR) | 1 | |
| 5504962 | 26 BRACKET AS | 1 | |
| 0307972 | 27 ELBOW | 1 | |
| 0L2070 | 28 BOLT (3/8-16X2.25-IN) | 4 | |
| 0S1588 | 29 BOLT (3/8-16X1.25-IN) | 4 | |
| 0S1594 | 30 BOLT (3/8-16X1-IN) | 52 | |
| 0S1617 | 31 BOLT (5/16-18X0.75-IN) | 6 | |
| 0S1618 | 32 BOLT (5/16-18X1-IN) | 8 | |
| 1920089 | 33 BOLT-SOCKET HEAD (1/4-20X1-IN) | 2 | |
| 1F7958 | 34 NUT-FULL (1/2-13-THD) | 8 | |
| 2088469 | 35 LOCKNUT (M6X1-THD) | 4 | |
| 2679817 | 36 BRACE | 1 | |
| 2725629 | 37 GUARD GP-FAN | 1 | |
| 3B4504 | 38 LOCKWASHER | 2 | |
| 3E9860 | 39 LOCKNUT (5/16-18-THD) | 2 | |
| 3E9865 | 40 LOCKNUT (1/4-20-THD) | 2 | |
| 3K6060 | 41 LOCKNUT (3/8-16-THD) | 4 | |
| 5333338 | 42 SEAL AS (TOP) | 1 | |
| 5333339 | 43 SEAL AS (BOTTOM) | 1 | |
| 1072207 | RIVET-POP | 8 | |
| 5M2894 | 44 WASHER-HARD (10.2X18.5X2.5-MM THK) | 72 | |
| 5P0537 | 45 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 5P8245 | 46 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T6974 | 47 BOLT (M6X1X80-MM) | 4 | |
| 7R7951 | 48 PLATE | 4 | |
| 8T1889 | 49 CLIP (SLOT) | 4 | |
| 8T1890 | 50 CLIP (TAB) | 4 | |
| 9F6580 | 51 BOLT (1/4-20X1.125-IN) | 2 | |
| 9M1974 | 52 WASHER-HARD (8.8X16X2-MM THK) | 16 | |
| 9R8537 | 53 SOCKET-LATCH | 2 | |
| 9S8750 | 54 NUT-FULL (1/4-20-THD) | 2 | |
| 9S8752 | 55 NUT-FULL (3/8-16-THD) | 12 | |
| 9X7380 | 56 SEAL-O-RING | 1 | |
| 9X7381 | 57 SEAL-O-RING | 1 | |
| 9X7383 | 58 SEAL-O-RING | 2 | |
| 5797039 | 59 BRACE | 1 |
