System And Components
540-0434 MOUNTING GP-DEF TANKS/N ZLK1-UP
Group No: 540-0434
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3650272 | 1 PAD | 1 | |
| 3875472 | 2 LANYARD (CAP) | 1 | |
| 3983011 | 3 CAP-TANK FILLER (DIESEL EXHAUST FLUID) | 1 | |
| 3996152 | 4 STRAP AS | 1 | |
| 4460473 | 5 ADAPTER AS | 1 | |
| 4458648 | ADAPTER-CAP | 1 | |
| 4512774 | SCREEN AS | 1 | |
| 4808743 | 6 BRACKET AS | 1 | |
| 2Y5829 | NUT (M10X1.5-THD) | 1 | |
| 5400446 | 7 TUBE AS | 2 | |
| 5457325 | 8 COVER | 1 | |
| 5457326 | 9 COVER AS-ACCESS | 1 | |
| 5P7970 | NUT (M8X1.25-THD) | 1 | |
| 5457335 | 10 BRACKET | 1 | |
| 1053478 | 11 BOLT-SOCKET HEAD (M10X1.5X35-MM) | 1 | |
| 1246262 | 12 CLAMP-HOSE | 6 | |
| 1925017 | 13 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3445675 | 14 NUT (M10X1.5-THD) | 4 | |
| 3920916 | 15 STRAP AS | 1 | |
| 2S3440 | 16 CLAMP-HOSE | 1 | |
| 6V1889 | 17 CLIP (LOOP) | 3 | |
| 7X7729 | 18 WASHER (11X25X3-MM THK) | 7 | |
| 8T4121 | 19 WASHER-HARD (11X21X2.5-MM THK) | 10 | |
| 8T4136 | 20 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4137 | 21 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4138 | 22 BOLT (M6X1X20-MM) | 6 | |
| 8T4185 | 23 BOLT (M10X1.5X50-MM) | 1 | |
| 8T4189 | 24 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4195 | 25 BOLT (M10X1.5X30-MM) | 9 | |
| 8T4224 | 26 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9X8256 | 27 WASHER (6.6X12X2-MM THK) | 6 | |
| 3496242 | 28 HOSE (13-CM) | ||
| 3496242 | 28A HOSE (9-CM) | ||
| 3496242 | 28B HOSE (7-CM) | ||
| 3679508 | 29 HOSE (120-CM) | ||
| 4735508 | KIT-STRAP | 1 |
