563-2410 WIRING GP-CAB -DOOR LATCHS/N ZLK1-UP

Group No: 563-2410

Part Number	Part Name	Qty
5645596	1 PLATE	1
0530189	2 GROMMET	1
1160118	3 CLIP	2
2235994	4 WASHER-SPRING	2
4D7794	5 CLIP	3
5198408	6 HARNESS AS-SENSOR (EXTENSION)	1
3214625	SLEEVE (146-CM)
3584101	PIN-CONNECTOR (16-GA TO 18-GA)	4
3748372	SOCKET-CONNECTOR (16-GA TO 18-GA)	4
5199378	7 MOUNT AS	1
6V8225	NUT (M6X1-THD)	2
5201102	8 SENSOR-POSITION (PROXIMITY)	1
5206620	9 WIRING GP-SENSOR	1
5145736	FILM-IDENTIFICATION (DOOR LATCH)	2
5206610	COVER AS	1
5206611	PLATE AS	1
5206621	HARNESS AS-LIGHTING	1
5P8244	WASHER-HARD (12X22.5X2.5-MM THK)	4
3214625	SLEEVE (40-CM)
3748372	SOCKET-CONNECTOR (16-GA TO 18-GA)	4
5208361	10 HARNESS AS-CAB (DOOR LATCH)	1
2715604	PIN-CONNECTOR (20-GA)	4
5644466	11 HARNESS AS-LIGHTING	1
3214625	SLEEVE (88-CM)
3584101	PIN-CONNECTOR (16-GA TO 18-GA)	4
3748372	SOCKET-CONNECTOR (16-GA TO 18-GA)	4
5660573	12 COVER AS	1
7T1099	LINK	2
5M3062	13 BOLT (3/8-16X0.75-IN)	1
6V8801	14 NUT (3/8-16-THD)	3
7K1181	15 STRAP-CABLE	7
8T0269	16 BOLT-SOCKET HEAD (M6X1X20-MM)	2
8T4171	17 BOLT (M6X1X12-MM)	2
8T4224	18 WASHER-HARD (8.8X16X2-MM THK)	3
8T4896	19 WASHER-HARD (10.2X18.5X2.5-MM THK)	6
8T4200	20 BOLT (M8X1.25X16-MM)	3
9B7237	21 BOLT (3/8-16X1.25-IN)	2
9G4191	22 GROMMET	1
9X2038	23 WASHER (7X19X2-MM THK)	2
9X8256	24 WASHER (6.6X12X2-MM THK)	2
