System And Components
461-6634 MOUNTING GP-SENSOR -NITROGEN OXIDEAN ATTACHMENT
Group No: 461-6634
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T9655 | 1 MOUNT-ISOLATION | 8 | |
| 9X6772 | 2 STRAP-CABLE | 1 | |
| 3250947 | 3 SPACER (8.48X12.7X32-MM THK) | 4 | |
| 3E6916 | 4 NUT-FULL (3/8-16-THD) | 4 | |
| 4415127 | 5 SENSOR AS-NITROGEN OXIDE (ENGINE OUTPUT) | 1 | |
| 4155724 | 6 PLATE | 1 | |
| 4616633 | 7 BRACKET AS | 1 | |
| 0S1594 | 8 BOLT (3/8-16X1-IN) | 5 | |
| 1D4538 | 9 BOLT (5/16-18X2.25-IN) | 4 | |
| 4M5281 | 10 BOLT (1/4-20X0.75-IN) | 2 | |
| 4P8134 | 11 CLIP (LADDER) | 1 | |
| 5M2894 | 12 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 5S0003 | 13 NUT (5/16-18-THD) | 4 | |
| 8T4205 | 14 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 9M1974 | 15 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9N0869 | 16 WASHER-HARD (8.8X25.5X2-MM THK) | 4 | |
| 0L1351 | 17 BOLT (3/8-16X0.875-IN) | 1 | |
| 9S8752 | 18 NUT-FULL (3/8-16-THD) | 1 | |
| 5458561 | 19 SHIELD AS | 1 | |
| 5458560 | 20 SHIELD AS | 1 | |
| 3353378 | 21 BLOCK | 1 | |
| 3353377 | 22 GASKET | 1 | |
| 3264516 | 23 TIE-CABLE | 1 | |
| 2856395 | 24 CLIP (LADDER) | 1 | |
| 1183508 | 25 GROMMET | 1 | |
| 1108314 | 26 WASHER (10.3X18.3X2.66-MM THK) | 8 | |
| 1077954 | 27 SPACER (10.2X22X8-MM THK) | 4 | |
| 5P7128 | 28 BOLT-HIGH TEMPERATURE (3/8-16X2-IN) | 4 |
