System And Components
507-2528 LINES GP-TURBOCHARGER OILS/N XWE1-UP
Group No: 507-2528 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1978418 | 1 GASKET | 1 | |
| 4627085 | 2 HOSE | 1 | |
| 5079917 | 3 HOSE & TUBE AS | 1 | |
| 5079918 | 4 TUBE AS | 1 | |
| 5118733 | 5 TUBE AS | 1 | |
| 1978419 | 6 GASKET | 1 | |
| 2109246 | 7 SEAL-O-RING | 1 | |
| 2843502 | 8 CLAMP-BAND | 2 | |
| 3196213 | 9 CONNECTOR AS | 1 | |
| 6V8634 | CONNECTOR | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 6V2317 | 10 BOLT (M8X1.25X30-MM) | 2 | |
| 6V5192 | 11 BOLT-SOCKET HEAD (M8X1.25X30-MM) | 2 | |
| 6V5218 | 12 BOLT (M8X1.25X35-MM) | 2 | |
| 9M1974 | 13 WASHER-HARD (8.8X16X2-MM THK) | 6 |
