Assembly
100%

502-5376 COOLING GPS/N SZT1-UP

Group No: 502-5376 · Commonality
Part NumberPart NameQty
8T41961 BOLT (M10X1.5X35-MM)7
8T46482 BOLT (M12X1.75X70-MM)1
3S20933 STRAP-CABLE2
4I75734 BRACE1
5P10765 WASHER-HARD (13.5X30X4-MM THK)4
7K11816 STRAP-CABLE2
7X77297 WASHER (11X25X3-MM THK)12
7Y16978 BRACE1
8T41369 BOLT (M10X1.5X25-MM)2
8T413710 BOLT (M10X1.5X20-MM)3
8T418311 BOLT (M12X1.75X40-MM)3
356930513 SPACER (13.5X30X40-MM THK)1
242609914 CLIP (LOOP)2
447171815 BOLT (M20X2.5X50-MM)4
453286616 WASHER-HARD (21.5X45X6-MM THK)4
502417817 TANK GP-COOLANT1
2513227CAP AS-COOLANT TANK1
506119918 SHEET AS-SOUND SUPPRESSION1
506120119 PIPE-WATER1
506833220 LINER1
506833321 LINER1
526905322 HOSE-WATER1
527049623 PLATE AS1
095139024 CLAMP-HOSE2
266737925 STRAP-CABLE1
511759026 MODULE GP-COOLING1
552884327 LINER1
552884428 LINER1
7Y197629 HOSE-WATER (156-CM)
5P564930 SEAL-BULK (1.1-M)
