System And Components
511-7588 RADIATOR & HYD OIL COOLER GPS/N SZT1-UP
Group No: 511-7588 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2366339 | 1 HOSE | 1 | |
| 1757141 | 2 NUT-HEX FLANGE (M10X1.5-THD) | 8 | |
| 3199804 | 3 GUARD | 1 | |
| 4756622 | 4 CORE AS-RADIATOR | 1 | |
| 4756623 | 5 CORE AS-OIL COOLER (HYDRAULIC) | 1 | |
| 3570003 | 6 PIN | 16 | |
| 4756627 | 7 FRAME AS-RADIATOR | 1 | |
| 4756633 | 8 BRACKET AS | 1 | |
| 4756643 | 9 BRACKET AS | 1 | |
| 4756652 | 10 SEAL-AIR | 2 | |
| 4756654 | 11 SEAL-AIR | 2 | |
| 4756656 | 12 SEAL-AIR | 2 | |
| 4756659 | 13 SEAL-AIR | 1 | |
| 4841456 | 14 STRAP-CABLE | 1 | |
| 5086337 | 15 PIPE AS | 1 | |
| 5086342 | 16 PLATE AS | 2 | |
| 5117544 | 17 FRAME AS | 1 | |
| 5117546 | 18 BRACKET AS | 1 | |
| 5117582 | 19 BRACKET | 1 | |
| 5117583 | 20 FRAME AS | 1 | |
| 5117584 | 21 FRAME AS | 1 | |
| 5411343 | 22 SEAL-AIR | 2 | |
| 5411345 | 23 SEAL-AIR | 1 | |
| 0964883 | 24 LOCKNUT (M10X1.5-THD) | 4 | |
| 1440367 | 25 CLAMP-HOSE | 4 | |
| 5D1026 | 26 CLAMP-BAND | 1 | |
| 5P1076 | 27 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 5P4116 | 28 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 7X2546 | 29 BOLT (M10X1.5X180-MM) | 8 | |
| 7X7729 | 30 WASHER (11X25X3-MM THK) | 30 | |
| 7Y5247 | 31 U-BOLT (M10X1.5-THD) | 2 | |
| 8T4121 | 32 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4136 | 33 BOLT (M10X1.5X25-MM) | 12 | |
| 8T4139 | 34 BOLT (M12X1.75X30-MM) | 8 | |
| 8T4182 | 35 BOLT (M10X1.5X45-MM) | 4 | |
| 8T4189 | 36 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4223 | 37 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T5001 | 38 BOLT (M12X1.75X130-MM) | 4 | |
| 5P0767 | 39 HOSE (43.6-CM) |
