Assembly
100%

511-7589 AFTERCOOLER GP-AIRS/N SZT1-UP

Group No: 511-7589 · Commonality
Part NumberPart NameQty
47566261 FRAME AS1
47566492 SEAL2
47566503 SEAL2
47566624 PIN8
51175415 CORE AS-AFTERCOOLER1
51175856 FRAME AS1
8T3490NUT-WELD (M10X1.5-THD)1
8T3597NUT-WELD (M12X1.75-THD)2
8T3612NUT-WELD (M8X1.25-THD)1
51175867 FRAME AS1
8T3490NUT-WELD (M10X1.5-THD)3
8T3612NUT-WELD (M8X1.25-THD)1
54113468 SEAL-AIR2
17571419 NUT-HEX FLANGE (M10X1.5-THD)4
7X254610 BOLT (M10X1.5X180-MM)4
7X772911 WASHER (11X25X3-MM THK)16
8T413612 BOLT (M10X1.5X25-MM)8
