System And Components
502-5360 PUMP GP-FUEL TRANSFERS/N SZT1-UP
Group No: 502-5360 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4192 | 1 BOLT (M12X1.75X25-MM) | 2 | |
| 8T4648 | 2 BOLT (M12X1.75X70-MM) | 1 | |
| 8T4121 | 3 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4136 | 4 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4137 | 5 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4223 | 6 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 1965650 | 7 SWITCH AS (REFUELING PUMP RELAY) | 1 | |
| 1976076 | NUT (M30X1-THD) | 1 | |
| 1976082 | BOOT | 1 | |
| 3685219 | 8 CONNECTOR-HOSE | 1 | |
| 4837804 | 9 SPACER (13.5X25X50-MM THK) | 1 | |
| 4841454 | 10 CLIP-RETAINING | 1 | |
| 5014186 | 11 VALVE GP-REFUELING (FOOT) | 1 | |
| 5139412 | 12 PLATE AS | 1 | |
| 5P5930 | SEAL (0.1-M) | ||
| 2724215 | GROMMET | 1 | |
| 5218981 | 13 PUMP GP-FUEL TRANSFER | 1 | |
| 5218986 | 14 PLATE AS | 1 | |
| 9M7958 | 15 CLAMP-HOSE | 4 | |
| 4571157 | 16 HOSE (460-CM) | ||
| 4571157 | 16A HOSE (40-CM) |
