504-3553 CABLE GP-GROUNDS/N SZT1-UP

Group No: 504-3553 · Commonality

Part Number	Part Name	Qty
8T6466	1 BOLT (M10X1.5X60-MM)	2
8T4908	2 BOLT (M8X1.25X25-MM)	3
2G8767	3 WASHER (10.5X60X3-MM THK)	4
6G2256	4 CLAMP	2
6G2263	5 SPACER (10.5X19X28.5-MM THK)	2
8T4121	6 WASHER-HARD (11X21X2.5-MM THK)	8
8T4136	7 BOLT (M10X1.5X25-MM)	1
8T4137	8 BOLT (M10X1.5X20-MM)	7
8T4224	9 WASHER-HARD (8.8X16X2-MM THK)	6
1321805	10 STRAP AS-GROUND	1
3280132	11 CABLE AS	1
9G0002	COVER AS-TERMINAL (RED)	1
9G0005	COVER AS-TERMINAL (BLACK)	1
8L8413	STRAP-CABLE (WHITE)	1
8C5918	TERMINAL AS-BATTERY (NEGATIVE)	1
8T9756	TERMINAL AS-BATTERY (POSITIVE)	1
1M6119	BOLT (5/16-18X1.375-IN)	1
1M6120	NUT (5/16-18-THD)	1
1598049	CABLE (00-GA, RED)(31-CM)
4841451	12 CLIP	6
4841456	13 STRAP-CABLE	2
5095001	14 CABLE AS (GROUND)	1
1S7252	TERMINAL-CABLE (00-GA, 3/8-IN SCREW)	1
6V2722	TUBE-HEAT SHRINK (25.4-MM DIA)(0.1-M)
1598050	CABLE (00-GA, BLACK)(25-CM)
2767278	TERMINAL-RING	1
5109082	15 PANEL GP-FUSE	1
1772215	16 STRAP-DUAL CLAMP	1
5513753	17 CABLE AS (FUSE)	1
0301705	TERMINAL-CABLE (00-GA, 5/16-IN SCREW)	1
1598049	CABLE (00-GA, RED)(68-CM)
6V2722	TUBE-HEAT SHRINK (25.4-MM DIA)(0.1-M)
9G0002	COVER AS-TERMINAL (RED)	1
8L8413	STRAP-CABLE (WHITE)	1
8T9756	TERMINAL AS-BATTERY (POSITIVE)	1
1M6119	BOLT (5/16-18X1.375-IN)	1
1M6120	NUT (5/16-18-THD)	1
5513754	18 CABLE AS (DISCONNECT)	1
1S7252	TERMINAL-CABLE (00-GA, 3/8-IN SCREW)	1
6V2722	TUBE-HEAT SHRINK (25.4-MM DIA)(0.1-M)
9G0005	COVER AS-TERMINAL (BLACK)	1
8L8413	STRAP-CABLE (WHITE)	1
9G8909	COVER-TERMINAL (BLACK)	1
8C5918	TERMINAL AS-BATTERY (NEGATIVE)	1
1M6119	BOLT (5/16-18X1.375-IN)	1
1M6120	NUT (5/16-18-THD)	1
1598050	CABLE (00-GA, BLACK)(54-CM)
5513755	19 CABLE AS-STARTER	1
1S7251	TERMINAL-CABLE (00-GA, 1/2-IN SCREW)	1
6V2722	TUBE-HEAT SHRINK (25.4-MM DIA)(0.1-M)
8N0869	COVER-TERMINAL (RED)	1
0301705	TERMINAL-CABLE (00-GA, 5/16-IN SCREW)	1
1598049	CABLE (00-GA, RED)(281-CM)
2042281	STRAP-CABLE	6
4841452	CLIP	6
5513756	20 BRACKET AS	1
8T3612	NUT-WELD (M8X1.25-THD)	3
