System And Components
576-8433 WIRING GP-CHASSIS -WORK LIGHTS, REARS/N SZT10001-UP
Group No: 576-8433 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2042281 | 1 STRAP-CABLE | 3 | |
| 1450603 | 2 GROMMET | 2 | |
| 2041611 | 3 STRAP-CABLE (DUAL) | 3 | |
| 2667379 | 4 STRAP-CABLE | 1 | |
| 3366307 | 5 BRACKET AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 5T6374 | 6 SPACER (11X20X40-MM THK) | 1 | |
| 4837805 | 7 SPACER (11X20X65-MM THK) | 2 | |
| 4841451 | 8 CLIP | 3 | |
| 4841452 | 9 CLIP | 3 | |
| 4841453 | 10 CLIP (RETAINER) | 1 | |
| 4841454 | 11 CLIP-RETAINING | 1 | |
| 4841456 | 12 STRAP-CABLE | 15 | |
| 5394147 | 13 BRACKET AS (CHASSIS) | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 5780210 | 14 PLATE | 1 | |
| 5782330 | 15 HARNESS AS-CHASSIS (WORK LIGHTS, REAR) | 1 | |
| 5782331 | 16 HARNESS AS-LIGHTING (WORK LIGHTS, REAR) | 1 | |
| 5782333 | 17 HARNESS AS-CHASSIS (SIDE, LH) | 1 | |
| 5782334 | 18 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 3S2093 | 19 STRAP-CABLE | 27 | |
| 5P4116 | 20 WASHER-HARD (8.8X20.5X2-MM THK) | 1 | |
| 7I2673 | 21 STRAP-CABLE | 1 | |
| 7K1181 | 22 STRAP-CABLE | 15 | |
| 8T4121 | 23 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4137 | 24 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4177 | 25 BOLT (M8X1.25X90-MM) | 1 | |
| 8T4178 | 26 BOLT (M10X1.5X90-MM) | 1 | |
| 8T4222 | 27 WASHER-PLATED (11X32X2.5-MM THK) | 1 | |
| 8T6466 | 28 BOLT (M10X1.5X60-MM) | 1 | |
| 4841456 | 29 STRAP-CABLE | 3 | |
| 3S2093 | 30 STRAP-CABLE | 3 |
