System And Components
504-3558 WIRING GP-ENGINES/N SZT1-UP
Group No: 504-3558 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4196 | 1 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4172 | 2 BOLT (M10X1.5X80-MM) | 3 | |
| 3S2093 | 3 STRAP-CABLE | 3 | |
| 5C7261 | 4 NUT (M8X1.25-THD) | 1 | |
| 7K1181 | 5 STRAP-CABLE | 11 | |
| 8T4121 | 6 WASHER-HARD (11X21X2.5-MM THK) | 19 | |
| 8T4133 | 7 NUT (M10X1.5-THD) | 2 | |
| 8T4136 | 8 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4137 | 9 BOLT (M10X1.5X20-MM) | 9 | |
| 1673583 | 10 STRAP AS-GROUND | 1 | |
| 2667379 | 11 STRAP-CABLE | 1 | |
| 4837806 | 12 SPACER (11X20X56-MM THK) | 3 | |
| 4841451 | 13 CLIP | 8 | |
| 4841454 | 14 CLIP-RETAINING | 1 | |
| 4841456 | 15 STRAP-CABLE | 2 | |
| 5095008 | 16 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 5133120 | 17 BRACKET AS | 1 | |
| 5133122 | 18 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 5133126 | 19 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 5227073 | 20 HARNESS AS-ENGINE (ALTERNATOR) | 1 | |
| 5283399 | 21 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 1772215 | 22 STRAP-DUAL CLAMP | 1 | |
| 2041611 | 23 STRAP-CABLE (DUAL) | 2 | |
| 5702258 | 24 HARNESS AS-ENGINE (FRONT) | 1 | |
| 5522526 | 25 CABLE AS-ENGINE | 1 | |
| 4900586 | BACKSHELL | 1 | |
| 3S2093 | STRAP-CABLE | 1 | |
| 4900571 | PLUG AS-CONNECTOR (2-PIN) | 2 | |
| 5522527 | 26 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 5543153 | 27 BRACKET AS-ENGINE | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 5702255 | 28 HARNESS AS-ENGINE (REAR) | 1 |
