System And Components
556-1460 DOOR GP-ACCESS -RADIATORS/N SZT1-UP
Group No: 556-1460 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5C9553 | 1 BOLT (M6X1X16-MM) | 8 | |
| 5P4116 | 2 WASHER-HARD (8.8X20.5X2-MM THK) | 21 | |
| 8T4121 | 3 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4136 | 4 BOLT (M10X1.5X25-MM) | 2 | |
| 9X8256 | 5 WASHER (6.6X12X2-MM THK) | 4 | |
| 0996418 | 6 NUT (M6X1-THD) | 4 | |
| 1358573 | 7 BOLT AS | 4 | |
| 1358575 | 8 BOLT AS | 4 | |
| 1953699 | 9 NUT (M8X1.25-THD) | 21 | |
| 5089591 | 10 HINGE | 2 | |
| 5089603 | 11 HANDLE AS | 1 | |
| 5848395 | 12 LOCK AS | 1 | |
| 5464983 | 13 SHEET | 1 | |
| 5477511 | 14 SHEET AS | 1 | |
| 5561468 | 15 SCREEN AS | 1 | |
| 5561473 | 16 SCREEN AS | 1 | |
| 5561471 | 17 SCREEN AS | 1 |
