575-9543 HOOD & GUARD GPS/N SZT10001-UP

Group No: 575-9543 · Commonality
Part NumberPart NameQty
54803311 HOOD GP-ENGINE (HINGED)1
4I19782 SPACER (24X38X4-MM THK)2
7Y28533 SPACER (13X38X5-MM THK)2
8T41214 WASHER-HARD (11X21X2.5-MM THK)2
8T41365 BOLT (M10X1.5X25-MM)2
13585756 BOLT AS30
13585777 BOLT AS7
17093608 GROMMET1
51031409 SHEET AS1
3485409SEAL (4-DM)
525978210 SHEET AS1
4K9429RIVET-POP4
9X6165WASHER (6.5X22X2.5-MM THK)4
5103370SHEET-RUBBER1
8T3597NUT-WELD (M12X1.75-THD)1
525978411 SHEET AS1
4K9429RIVET-POP6
9X6165WASHER (6.5X22X2.5-MM THK)6
5103372SHEET-RUBBER1
8T3597NUT-WELD (M12X1.75-THD)2
548019412 SHEET AS-SOUND SUPPRESSION1
528357213 SHEET AS1
8T3490NUT-WELD (M10X1.5-THD)1
8T3597NUT-WELD (M12X1.75-THD)3
5283661INSULATION1
535917114 SHEET AS1
8T3490NUT-WELD (M10X1.5-THD)2
548019115 SHEET AS1
4I7924WASHER (4.5X40X1.2-MM THK)2
6P2216CAP (PUSH ON)2
5103399SILENCER1
8T3597NUT-WELD (M12X1.75-THD)2
548030016 HANDLE AS1
548041317 SHEET AS-SOUND SUPPRESSION1
576947118 COVER AS-ENCLOSURE1
1019848SEAL (0.9-M)
8T3597NUT-WELD (M12X1.75-THD)1
