System And Components
536-7288 DRIVE GP-SWING -WITHOUT MOTORS/N SZT1-UP
Group No: 536-7288 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5705850 | 1 GEAR-SUN | 1 | |
| 5705851 | 2 HOUSING AS-DRIVE | 1 | |
| 5705852 | 3 HOUSING-OUTPUT | 1 | |
| 5705853 | 4 SHAFT-PINION | 1 | |
| 5705854 | 5 NUT-RING (M102X2-THD) | 1 | |
| 5705855 | 6 SPACER | 1 | |
| 5705856 | 7 RING-RETAINING | 1 | |
| 5705857 | 8 SEAL | 2 | |
| 5705858 | 9 SEAL | 1 | |
| 5705860 | 10 SEAL-RING | 1 | |
| 5705861 | 11 BEARING | 1 | |
| 5705862 | 12 BEARING | 1 | |
| 5705863 | 13 SHIM-PACK | 1 | |
| 5705864 | 14 PLANETARY AS | 1 | |
| 5705865 | 15 PLANETARY AS | 1 | |
| 5694288 | 16 GEAR-RING | 1 | |
| 1368074 | 17 PLUG-DRAIN | 2 | |
| 3110501 | 18 BOLT (M8X1.25X25-MM) | 10 |
